JLG 1500AJP Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
39.8in
B
Overall Width
16.61ft in
C
Overall Height - Mast Lowered
10.2ft in
E
Ground Clearance
1in
Articulation Angle
130 degrees
Tailswing Radius
2.5ft in
Turning Radius
31.3ft in
Up And Over Height
60ft in
Platform Dimension A
3ft in
Platform Dimension B
8ft in
Platform
Platform Capacity - Restricted
1000lb
Platform Capacity - Unrestricted
600lb
Platform Railing Height
150ft in
Specifications
Swing System
Swing
360degrees
Swing Type
Continuous
Engine
Diesel Engine Type
Deutz TCD 3.6 T4F
Diesel Engine Power
99.8hp
Maximum Ground Bearing Pressure
120psi
System Voltage
12V
Operational
Operating Weight
57400lb
Fuel Capacity
45gal
Hydraulic System Fluid Capacity
36gal
Tire Size
445/50D710 24 Ply FF
Performance
Axle Oscillation
1ft in
Drive Speed
2.8mph
Gradeability
40%
