Mustang 519 Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
12.33ft in
E
Ground Clearance
14ft in
B
Width Over Tires
5.92ft in
C
Overall Height
6.33ft in
D
Wheelbase
7.5ft in
Turning Radius Outside Tires
11ft in
Lift
F
Max Lift Height
19.08ft in
G
Max Forward Reach
11ft in
Max Load At Max Reach
1850lb
Max Load At Max Height
3000lb
Max Lift Capacity
5500lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2349
Engine Model
TD2009 L04
Gross Power
156hp
Power Measured @
2600rpm
Aspiration
Turbocharged
Engine Rpm - Rated
2200rpm
Cat Diesel Engines
C6.6 Tier 3
Operational
Operating Weight
10000lb
Fuel Capacity
17gal
Hydraulic System Fluid Capacity
18gal
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed - Forward
15mph
Max Speed - Reverse
15mph
Weights
Operating Weight
19099lb
Operating Weight*
19099lb
Counterweight
1100lb
Hydraulic
Pump Type
Gear
Pump Flow Capacity
22gal/min
Relief Valve Pressure
3350psi
Hydraulic System
System Pressure
2250 psi
Swing Speed
8rpm
Flows At Rated Speed
166, 124, 83 L/min (44, 33, 22 gal/min)
Operating Specifications
Knuckleboom Length
27ft in
Swing Bearing - Diameter - Od
43in
Stabilizers (4) - Pad Size
55.8 cm 66 cm (22 in 26 in)
Service Refill Capacities
Fuel
71gal
Hydraulic
35gal
