Airman AX40U-4 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
17.52ft in
C
Shipping Height Of Unit
8.37ft in
J
Max Loading Height
12.87ft in
K
Max Reach Along Ground
18.87ft in
L
Max Vertical Wall Digging Depth
8.86ft in
M
Max Digging Depth
11ft in
Dimensions
B
Width To Outside Of Tracks
6.44ft in
D
Length Of Track On Ground
6.57ft in
E
Ground Clearance
1.1ft in
H
Tail Swing Radius
3.22ft in
Undercarriage
N
Shoe Size
15.75in
Max Travel Speed
2.8mph
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV88
Gross Power
40hp
Power Measured @
2500rpm
Displacement
133.6cu in
Operational
Operating Weight
9656.3lb
Hydraulic System Relief Valve Pressure
3481psi
Hydraulic Pump Flow Capacity
33.1gal/min
Buckets
Reference Bucket Capacity
0.2yd3
