ASV RC50 Turf Edition Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5ft in
C
Height To Top Of Cab
6.42ft in
E
Ground Clearance
12.01in
Length With Out Bucket
8.34ft in
Length With Bucket
10.67ft in
Undercarriage
D
Length Of Track On Ground
4.92ft in
I
Track Gauge
3.75ft in
Ground Contact Area
1767.01in2
Ground Pressure
3.11psi
Width Of Track
15in
Specifications
Engine
Engine Make
2351
Engine Model
404C-22
Gross Power
50hp
Power Measured @
2800rpm
Peak Torque
105lb ft
Displacement
134cu in
Operational
Operating Weight
6200lb
Cooling System Fluid Capacity
2gal
Engine Oil Capacity
2.9gal
Fuel Capacity
15.1gal
Hydraulic System Fluid Capacity
8.1gal
Operating Voltage
12V
Alternator Supplied Amperage
55amps
Max Speed - High Range
8.1mph
Loader
Operating Load
1900lb
Tipping Angle
3800degrees
Hydraulic
Pump Flow
16.3gal/min
Relief Valve Pressure
3000psi
