ASV SR80 Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
6.01ft in
C
Height To Top Of Cab
7.17ft in
E
Ground Clearance
15in
G
Clearance At Max Lift And Dump
8.17ft in
H
Reach At Max Lift And Dump
1.67ft in
Length With Bucket
11.84ft in
Length With Out Bucket
9.34ft in
Undercarriage
D
Length Of Track On Ground
5.92ft in
Ground Pressure
3.15psi
Width Of Track
20in
Ground Contact Area
2840in2
Specifications
Engine
Number Of Cylinders
4
Engine Make
2351
Engine Model
804C-33T
Gross Power
80.5hp
Net Power
78hp
Power Measured @
2600rpm
Peak Torque
186lb ft
Displacement
201.4cu in
Aspiration
Turbocharged
Operational
Operating Weight
8972lb
Fuel Capacity
18gal
Hydraulic System Fluid Capacity
21gal
Max Speed - Low Range
7mph
Max Speed - High Range
12.5mph
Loader
Operating Load
3100lb
Tipping Angle
6200degrees
Hydraulic
Pump Flow
30gal/min
Relief Valve Pressure
3000psi
