Belle 761XS Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
9.93ft in
B
Width Over Tires
4.84ft in
E
Ground Clearance
10in
C
Height To Top Of Cab
6.74ft in
D
Wheelbase
2.92ft in
F
Length W/O Bucket
7.87ft in
G
Clearance At Max Lift And Dump
7.47ft in
H
Reach At Max Lift And Dump
21.26in
Turning Radius From Center - Machine Rear
43.63in
Turning Radius From Center - Inc Bucket
69.73in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2351
Engine Model
104-22
Net Power
48hp
Power Measured @
2600rpm
Aspiration
Natural
Displacement
135.3cu in
Operational
Operational Weight
5381lb
Fuel Capacity
13.8gal
Hydraulic System Fluid Capacity
14.6gal
Tire Size
10 x 16.5
Loader
Breakout Force
3616lb
Operating Load Rating
1378lb
Tipping Angle
2756degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
15.9gal/min
Relief Valve Pressure
2842psi
