Broderson IC80-3G Rough Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
20ft in
J
Max Height @ Max Raise Angle - No Jib
37.42ft in
K
Min Operating Radius
5ft in
M
Max Elevating Angle
70degrees
L
Max Operating Radius
40ft in
Number Of Sections
3
Max Lift Capacity
18000lb
Swing Speed
2rpm
Dimensions
A
Transport Length
17.73ft in
B
Transport Width
6.5ft in
C
Transport Height
7.25ft in
D
Wheelbase
7.17in
E
Ground Clearance
0.58ft in
F
Width W/ Outriggers Extended
9.58ft in
G
Carrier/Base Length
12.81ft in
H
Upper Structure Tail Swing Radius
4.76ft in
Specifications
Engine
Engine Model
GM 3.0 EFI
Gross Power
69hp
Max Torque
163lb ft
Displacement
181cu in
Operational
Operating Weight
16660lb
Fuel Capacity
20gal
Hydraulic System Fluid Capacity
25gal
Operating Voltage
12V
Alternator Supplied Amperage
66amps
Tire Size
10.00x15
Transmission
Transmission Type
powershift
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
20mph
Max Speed - Reverse
20mph
