BT C3E180 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.67ft in
B
Overall Width
3.31ft in
C
Overall Height - Mast Lowered
6.76ft in
D
Wheelbase
4.63ft in
E
Ground Clearance
3.55in
F
Height To Top Of Overhead Guard
6.4ft in
G
Max Fork Height
9.75ft in
Turning Radius
5.47ft in
Mast
H
Mast Tip Forward
2.3degrees
I
Mast Tip Rear
6degrees
Lower Speed
98.43ft/min
Load Capacity
3968.33lb
Load Center
19.69in
Lift Speed
118.12ft/min
Specifications
Engine
Power
16.1hp
Fuel Type
electric
Operational
Operating Weight
7440.7lb
Tire Type
front 200/50-10 rear 16x6-8
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
9.1mph
