Case 650K LGP Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
14.03ft in
B
Width Over Tracks
7.67ft in
C
Height To Top Of Cab
9.1ft in
D
Length Of Track On Ground
7.32ft in
E
Ground Clearance
1.26ft in
Undercarriage
G
Track Gauge
5.58ft in
H
Standard Shoe Size
25in
Track Pitch
6.74in
Number Of Shoes Per Side
38
Ground Pressure
4.41psi
Number Of Carrier Rollers Per Side
1
Ground Contact Area
4390in2
Number Of Track Rollers Per Side
6
Specifications
Engine
Number Of Cylinders
4
Engine Make
2239
Engine Model
Family III 445T/M2 diesel
Gross Power
80hp
Net Power
74.8hp
Power Measured @
2000rpm
Max Torque
262lb ft
Displacement
274cu in
Torque Measured @
1400rpm
Operational
Operating Weight
19400lb
Fuel Capacity
50gal
Cooling System Fluid Capacity
5gal
Engine Oil Capacity
3.6gal
Hydraulic Fluid Capacity
20gal
Final Drives Fluid Capacity
3.8gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
Hydrostatic
Max Speed - Forward
6mph
Max Speed - Reverse
6mph
Hydraulic System
Relief Valve Pressure
3025psi
Pump Flow Capacity
20.8gal/min
Standard Blade
Width
10.4ft in
Height
36in
Capacity
2.6yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
19in
