Case CX14 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
10.96ft in
I
Max Cutting Height
11.91ft in
C
Shipping Height Of Unit
7.22ft in
J
Max Loading Height
8.4ft in
K
Max Reach Along Ground
12.08ft in
L
Max Vertical Wall Digging Depth
6.04ft in
M
Max Digging Depth
6.93ft in
Boom/Stick Option (Hex) 1
Boom 5'3" (1610mm)/ Stick 3'4" (1020mm)
Dimensions
B
Width To Outside Of Tracks
3.94ft in
D
Length Of Track On Ground
3.97ft in
E
Ground Clearance
0.58ft in
G
Height To Top Of Cab
7.22ft in
H
Tail Swing Radius
1.94ft in
Removal Counterweight Clearance
1.42ft in
Undercarriage
N
Shoe Size
9.06in
Max Travel Speed
2.3mph
Ground Pressure
3.1psi
Number Of Track Rollers Per Side
3
Specifications
Engine
Number Of Cylinders
3
Engine Make
2348
Engine Model
3TNE68
Net Power
11.9hp
Power Measured @
2000rpm
Displacement
47.8cu in
Max Torque
34lb ft
Torque Measured @
1500rpm
Operational
Operating Weight
3240lb
Fuel Capacity
4gal
Cooling System Fluid Capacity
0.7gal
Hydraulic System Fluid Capacity
4.5gal
Engine Oil Capacity
0.9gal
Operating Voltage
12V
Alternator Supplied Amperage
20amps
Hydraulic System Relief Valve Pressure
2988psi
Hydraulic Pump Flow Capacity
7.8gal/min
Swing Mechanism
Swing Speed
10.7rpm
Buckets
Reference Bucket Capacity
0.1yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.1yd3
