Case CX300C Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
34.29ft in
C
Shipping Height Of Unit
10.7ft in
I
Max Cutting Height
33.01ft in
J
Max Loading Height
23.27ft in
K
Max Reach Along Ground
34.45ft in
M
Max Digging Depth
23.3ft in
Boom/Stick Option (Hex) 1
Boom - 6.15 m / Arm - 3.18 m
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
34.39ft in
I
Max Cutting Height
32.58ft in
C
Shipping Height Of Unit
10.96ft in
J
Max Loading Height
22.77ft in
K
Max Reach Along Ground
32.94ft in
M
Max Digging Depth
21.56ft in
Boom/Stick Option (Hex) 2
Boom - 6.15 m / Arm - 2.65 m
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
34.36ft in
I
Max Cutting Height
34.09ft in
J
Max Loading Height
24.25ft in
C
Shipping Height Of Unit
11.36ft in
K
Max Reach Along Ground
36.06ft in
M
Max Digging Depth
24.87ft in
Boom/Stick Option (Hex) 3
Boom - 6.15 m / Arm - 3.66 m
Dimensions
E
Ground Clearance
1.55ft in
G
Height To Top Of Cab
10.7ft in
B
Width To Outside Of Tracks
9.49ft in
D
Length Of Track On Ground
34.29ft in
H
Tail Swing Radius
10.37ft in
Cab Height
126.38in
Wheelbase
13.06ft in
Undercarriage
Number Of Track Rollers Per Side
9
Ground Pressure
8.27psi
Drawbar Pull
52380.48lb
Number Of Shoes Per Side
50
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.36mph
Specifications
Engine
Number Of Cylinders
6
Engine Make
ISUZU
Engine Model
AL-6HK1X
Gross Power
206.6hp
Power Measured @
1800rpm
Max Torque
663.9lb ft
Displacement
475.4cu in
Torque Measured @
1500rpm
Bore
4.6in
Stroke
5in
Operational
Operating Weight
65036.4lb
Fuel Capacity
118.9gal
Cooling System Fluid Capacity
8.2gal
Hydraulic System Fluid Capacity
79.3gal
Hydraulic Pump Flow Capacity
128.4gal/min
Swing Mechanism
Swing Speed
10rpm
