Case IH Farmall 75C 2WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
12.98in
D
Wheelbase
7ft in
B
Overall Width
7.76ft in
Height With Out Rops
6.3ft in
Height With Rops
7.97ft in
Specifications
Engine
Number Of Cylinders
4
Gross Power
76hp
Pto Power
62hp
Power Measured @
2300rpm
Torque Measured @
1400rpm
Displacement
195.3cu in
Aspiration
turbocharged, intercooled
Operational
Operating Weight
5588lb
Fuel Capacity
19.9gal
3 Point Hitch Lift Capacity @ 24 Inches
3960lb
Alternator Supplied Amperage
120amps
Transmission
Transmission Type
16 x 16 w/ mechanical shuttle
Number Of Forward Gears
16
Number Of Reverse Gears
16
Max Speed
18.7mph
Hydraulic System
Relief Valve Setting
2755psi
Pump Flow Capacity
20.2gal/min
Number Of Remote Control Valves
1
