Case IH JX1075N MFWD Tractor
Units
Dimensions
Dimensions
A
Overall Length
12.8in
D
Wheelbase
6.76ft in
B
Overall Width
4.46ft in
E
Ground Clearance
10.48in
Height With Out Rops
4.28ft in
Height With Rops
7.26ft in
Specifications
Engine
Number Of Cylinders
3
Gross Power
75hp
Pto Power
62hp
Power Measured @
2300rpm
Max Torque
221.3lb ft
Torque Measured @
1400rpm
Displacement
177cu in
Aspiration
Turbocharged
Operational
Operating Weight
5886lb
Fuel Capacity
15gal
3 Point Hitch Lift Capacity @ 24 Inches
3962lb
Rear Tires Size 2wd/4wd
380/70R24
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
16 x 16 w/ mechanical shuttle
Number Of Forward Gears
16
Number Of Reverse Gears
16
Max Speed
18.4mph
Hydraulic System
Relief Valve Setting
2610psi
Pump Flow Capacity
23.4gal/min
Number Of Remote Control Valves
2
