Case IH LB334 STANDARD Baler
Units
Dimensions
Baler Pickup
Number Of Tines
56 double (112)
Outer Tine-To-Tine Width
70.16in
Pickup Working Width
77.49in
Tine Spacing
2.6in
Gauge Wheels
Two 15x6.00-6 4PR
Number Of Tine Bars
4
Number Of Tine Rows
4
Dimensions
Tractor Pto Power Required
104.6hp
Height Tandem Axle
123.35in
Height, Single Axle
123.35in
Length With Bale Chute Folded
294.38in
Baler Width
101.11in
Specifications
Knotters
Knotters Type
Double knot
Number Of Knotters
4
Twine Ball Storage Quantity
32
Maindrive
Main Drive Protection
Shearbolt, overrunning clutch & slip clutch
Sales Literature
Literature Number
CIH07211201
Literature Date
July, 2012
Document Number
HF-5138-12
Document Date
July, 2012
Years Of Manufacture
Manufacturing Status
Current
First Entry Date
August,2012
Revision Date
July, 2016
Engine
Pto Speed
1000rpm
Number Of Remote Hydraulic Valves
2
Bale Size
Bale Height
35.5in
Bale Width
31.5in
Bale Length - Max
108in
Feeding
Feeder Description
2 packer forks, 6 single tines
Stuffer Description
Fork,4 tines
Weights
Weight Single Axle
17747.3lb
Tires
Tire Size Single Axle
600/55x22.5 up to 700/40 R22.5
Weights
Weight Tandem Axle
19070lb
Tires
Tire Size Tandem Axle
500/50-17 or 550/45 R22.5
Plunger
Density Control
3-way monitor control
Plunger Speed (Strokes/Min)
48
Plunger Stroke
28in
