Case IH MAGNUM 340 ROWTRAC 4WD Tractor
Units
Dimensions
Dimensions
C
Height To Top Of Cab
135.83in
D
Wheelbase
10.34ft in
Length
249.3in
Overall Width (Axles Extended)
93-182 in, 2362-4623 mm
Specifications
Drawbar
Description
Category 4, adjustable
Electrical System
System
12V
Alternator
200amps
Engine
Fuel Injection
Direct
Emissions Level
Final Tier 4B
Number Of Cylinders
6
Def Tank Capacity
26.2gal
Advertised Rated Engine Power
340.7hp
Maximum Engine Power
410.4hp
Power Boost
69.8hp
Pto Horsepower
289.7hp
Pto Operational Type
Independent
Block Design
Wet liners
Fuel System Control
Electronic
Steering Configuration
Front Steer
Drive Wheels / Tracks
2 Rear tracks + 2 MFD front tires
Engine Make
Case IH FPT
Engine Model
Magnum 340 Rowtrac
Rated Engine Speed
2000rpm
Fuel Tank Capacity
178.1gal
Displacement
531cu in
Bore
4.7in
Stroke
5.4in
Aspiration
eVGT Turbocharged, Aftercooled
Fan Drive Type
BorgWarner Visctronic
Fuel System
High Pressure Common Rail
Transmission
Manufacturers Description
PowerDrive
Transmission Type
Full Powershift
Maximum Speed Forward
24.9mph
Number Of Forward Gears
18
Number Of Reverse Gears
4
Weights
Weight Without Ballast
39248.9lb
Tires
Track Widths
16-18-24-30 in, 406-457-610-762 mm
Front
IF420/85 R38 R1W
Rear
IF420/85 R38 R1W
Hydraulic System
Hydraulic System Type
Pressure Flow Compensated
Main Pump Type
Variable Displacement
Axles
Axle Output End
Flange w/ drive sprocket
Hydraulic System
Implement Pump Flow
43.9gal/min
Axles
Final Drive
Inboard / Planetary
Hydraulic System
Number Of Remote Control Valves
4 - standard, 5 or 6 - optional
3-Point Hitch
Category
Category 3 / 4N
Lift Capacity @ 24”
19899lb
Draft Sensing
Electronic position and/or draft control
Brakes
Service Brake
Wet disc
