Case IH Maxxum 125 2WD Tractor
Units
Dimensions
Dimensions
D
Wheelbase
8.71ft in
Height With Rops
9.51ft in
Specifications
Engine
Number Of Cylinders
6
Gross Power
125hp
Pto Power
105hp
Power Measured @
2200rpm
Displacement
412cu in
Aspiration
turbocharged, aftercooled
Operational
Operating Weight
10348lb
Fuel Capacity
66.1gal
3 Point Hitch Lift Capacity @ 24 Inches
7509lb
Rear Tires Size 2wd/4wd
18.4R34
Alternator Supplied Amperage
120amps
Transmission
Transmission Type
Synchro
Number Of Forward Gears
12
Number Of Reverse Gears
12
Hydraulic System
Pump Flow Capacity
27.1gal/min
Number Of Remote Control Valves
2
