Case IH STEIGER 485 4WD Tractor
Units
Dimensions
Dimensions
B
Width Outside Frame
3.65ft in
D
Wheelbase
153.94in
Front Axle Clearance
44.89in
Rear Axle Clearance
3.75ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
Iveco
Gross Power
485hp
Pto Power
429hp
Power Measured @
2000rpm
Displacement
787.3cu in
Bore
5.4in
Stroke
6in
Aspiration
Turbocharged
Operational
Operating Weight
54000.1lb
Fuel Capacity
300gal
Engine Oil Capacity
8.2gal
Front Tire Size
710/70R42
3 Point Hitch Type
4N
3 Point Hitch Lift Capacity @ 24 Inches
19620lb
Rear Tire Size
710/70R42
Operating Voltage
12V
Alternator Supplied Amperage
175amps
Transmission
Transmission Type
Full power shift
Number Of Forward Gears
16
Number Of Reverse Gears
2
Max Speed - Forward
19.7mph
Max Speed - Reverse
8.5mph
Hydraulic System
Hydraulic System Type
Parallel pressure flow compensated
Pump Flow Capacity
40gal/min
Number Of Remote Control Valves
4 to 5
