Caterpillar 160M2 Motor Grader
Dimensions
Dimensions
Overall Length
29.2ft in
Width Over Tires
8.47ft in
Wheelbase
20.1ft in
Rear Ground Clearance
1.13ft in
Tandem Axle Wheelbase
5ft in
Front Ground Clearance
1.97ft in
Blade Base
8.39ft in
Height To Top Of Isomount Cab
10.79ft in
Specifications
Ripper
Pry-Out Force
258201lb
Ripping Depth - Maximum
16.8in
Ripper Shank Holders
5
Penetration Force
20443lb
Machine Length Increase, Beam Raised
40.6in
Ripper Shank Holder Spacing
21in
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
C9.3 ACERT VHP
Frame
Front Frame Structure - Height
1.1ft in
Front Frame Structure - Width
0.9ft in
Engine
Power Measured @
2100rpm
Torque Measured @
2100rpm
Net Power Gears 7-8
243hp
Net Torque Gears 7-8
1000lb ft
Bore
4.5in
Stroke
5.9in
Emissions
U.S. Tier 4 Interim/EU Stage IIIB
Engine Model
Cat C9.3 ACERT
Derating Altitude
10000ft in
Maximum Torque
1000lb ft
Base Power (1st Gear) - Net
213hp
Standard Capability
109degrees
Speed At Rated Power
2,100 rpm
High - Ambient Capability
122degrees
Base Power (1st Gear) - Net - Metric
216hp
High Ambient - Fan Speed - Maximum
1,550 rpm
High Ambient - Fan Speed - Standard
1,400 rpm
High Ambient - Fan Speed - Minimum
500 rpm
Vhp Plus Range - Net
159-196 kW (213-263 hp)
Vhp Plus Range - Net - Metric
159-196 kW (216-267 hp)
Frame
Circle - Diameter
60.2in
Drawbar - Height
6in
Front Axle - Height To Center
23.6in
Circle - Blade Beam Thickness
1.6in
Front Axle - Total Oscillation Per Side
32 degrees
Drawbar - Thickness
0.5in
Drawbar - Width
3in
Front-Top/Bottom Plate - Width
12in
Front-Top/Bottom Plate - Thickness
0.9in
Front Axle - Wheel Lean - Left/Right
18 degrees
Engine
Vhp Plus - Gear 1f, Net
213hp
Vhp Plus - Gear 2f, Net
223hp
Vhp Plus - Gear 3f, Net
233hp
Vhp Plus - Gear 4f, Net
243hp
Vhp Plus - Gear 5f, Net
248hp
Vhp Plus - Gear 6f, Net
253hp
Vhp Plus - Gear 7f, Net
258hp
Vhp Plus - Gear 8f, Net
263hp
Base Power (All Gears) - Net
213hp
Operational
Std Operation Weight - Front Axle
9339lb
Hydraulic System Fluid Capacity
26.4gal
Std Operation Weight - Rear Axle
28792lb
Std Operation Weight - Total
38131lb
Max Operation Weight - Front Axle
13343lb
Max Operation Weight - Rear Axle
36444lb
Max Operation Weight - Total
52795lb
Oil System Fluid Capacity
7.9gal
Fuel Capacity
110gal
Cooling System Fluid Capacity
14.8gal
Transmission Fluid Capacity
17.2gal
Circle Gearbox Fluid Capacity
1.8gal
Tandem Case Fluid Capacity (Each)
16.9gal
Operating Voltage
24V
Alternator Supplied Amperage
150amps
Power Train
Brakes - Parking
Multiple Oil Disc
Brakes - Service
Multiple Oil Disc
Transmission
Direct Drive Powershift
Forward/Reverse Gears
8 Fwd/6 Rev
Brakes - Secondary
Dual Circuit Control
Brakes - Service - Surface Area
3565in2
Steering
Articulation Angle
20degrees
Turning Radius
25.5ft in
Transmission
Transmission Type
Direct Drive, Powershift
Number Of Gears - Forward
8
Number Of Gears - Reverse
6
Max Speed - Forward
29mph
Max Speed - Reverse
22.9mph
Front Axle
Wheel Lean
18degrees
Oscillation - Total
32degrees
Ground Clearance
2ft in
Weights
Operating Weight - Typically Equipped
45283lb
Gross Vehicle Weight - Base - Total
38790lb
Gross Vehicle Weight - Maximum - Total
54869lb
Operating Weight - Typically Equipped - Total
45283lb
Gross Vehicle Weight - Base - Rear Axle
28786lb
Operating Weight - Typically Equipped - Front Axle
13171lb
Operating Weight - Typically Equipped - Rear Axle
32112lb
Gross Vehicle Weight - Base - Front Axle
10004lb
Gross Vehicle Weight - Maximum - Front Axle
17009lb
Gross Vehicle Weight - Maximum - Rear Axle
37860lb
Hydraulic System
Standby Pressure
609 psi
Maximum System Pressure
3503 psi
Moldboard
Moldboard Width
14ft in
Moldboard Height
24in
Moldboard Thickness
0.9in
Max Depth Of Cut
29.6in
Side Shift Left
20.1in
Side Shift Right
26in
Blade Pull At Max Weight
20044lb
Blade Down Pressure
22884lb
Hydraulic System
Pump Type
Variable Piston
Pump Flow
55.5gal/min
Relief Valve Pressure
3503psi
Circuit Type
Parallel
Pump Output
55.5 gal/min
Reservoir Tank Capacity
15.9gal
Moldboard
Blade Width
14ft in
Arc Radius
16.3in
Throat Clearance
6.5in
Cutting Edge Width
6in
Cutting Edge Thickness
0.6in
End Bit - Width
6in
End Bit - Thickness
0.6in
Moldboard - Height
24in
Moldboard - Thickness
0.9in
Blade Pull - Maximum Gvw
34072lb
Blade Pull - Base Gvw
25908lb
Blade Down Pressure - Base Gvw
17171lb
Blade Down Pressure - Maximum Gvw
29195lb
Circle
Diameter
60.3in
Rotation
360degrees
Shift Left
27.4in
Shift Right
28.7in
Max Reach Outside Tires - Left
82.3in
Max Reach Outside Tires - Right
89.7in
Max Lift Above Ground
17.8in
Blade Tip Angle - Front
40degrees
Blade Tip Angle - Rear
5degrees
Operating Specifications
Top Speed - Forward
29.5mph
Top Speed - Reverse
23.3mph
Turning Radius - Outside Front Tires
25ft in
Steering Range - Left/Right
47.5 degrees
Articulation Angle - Left/Right
20 degrees
Forward - 8th
29.5mph
Forward - 7th
20.3mph
Forward - 6th
14.7mph
Forward - 5th
10.8mph
Forward - 4th
7mph
Forward - 3rd
5.1mph
Forward - 2nd
3.5mph
Forward - 1st
2.6mph
Reverse - 6th
23.3mph
Reverse - 5th
16mph
Reverse - 4th
8.5mph
Reverse - 3rd
5.5mph
Reverse - 2nd
3.8mph
Reverse - 1st
2mph
Standards
Brakes
ISO 3450, ISO 10265
Rops/Fops
ISO 3471/ISO 3499
Sound
ISO 6394; ISO 6395
Steering
ISO 5010
Service Refill
Cooling System
14.8gal
Hydraulic System - Total
26.4gal
Engine Oil
7.9gal
Hydraulic System - Tank
16.9gal
Tandem Housing - Each
16.9gal
Circle Drive Housing
1.8gal
Front Wheel Spindle Bearing Housing
0.2gal
Fuel Capacity
110gal
Transmission - Differential - Final Drives
17.2gal
Blade Range
Circle Centershift - Right
28.7in
Circle Centershift - Left
27.4in
Moldboard Sideshift - Right
26in
Moldboard Sideshift - Left
20.1in
Blade Tip Range - Forward
40 degrees
Blade Tip Range - Backward
5 degrees
Maximum Shoulder Reach Outside Of Tires - Right
89.7in
Maximum Shoulder Reach Outside Of Tires - Left
82.3in
Maximum Lift Above Ground
17.8in
Maximum Depth Of Cut
29.5in
Maximum Blade Position Angle
90 degrees
Scarifier
Front, V-Type - Working Width
47.4in
Rear - Scarifier Shank Holders
9
Mid, V-Type - Scarifier Shank Holders
11
Front, V-Type, 5 Or 11 Tooth - Working Width
40.6in
Front, V-Type, 5 Or 11 Tooth - Scarifying Depth, Maximum
18.4in
Front, V-Type, 5 Or 11 Tooth - Scarifier Shank Holders
5/11
Front, V-Type, 5 Or 11 Tooth - Scarifier Shank Holder Spacing
4.6in
Mid, V-Type - Working Width
46.6in
Mid, V-Type - Scarifying Depth, Maximum
11.5in
Mid, V-Type - Scarifier Shank Holder Spacing
4.6in
Rear - Working Width
84in
Rear - Scarifying Depth, Maximum
16.8in
Rear - Scarifier Shank Holder Spacing
10.5in
Front, V-Type - Scarifying Depth, Maximum
40.6in
Front, V-Type - Scarifier Shank Holders
5/11
Front, V-Type - Scarifier Shank Holder Spacing
18.4in
Mid, Straight - Working Width
70.9in
Mid, Straight - Scarifier Shank Holder Spacing
4.4in
Mid, Straight - Scarifier Shank Holders
17
Mid, Straight - Scarifying Depth, Maximum
12.5in
Tandems
Height
19.9in
Width
8.3in
Sidewall Thickness - Inner
0.7in
Sidewall Thickness - Outer
0.8in
Drive Chain Pitch
2in
Wheel Axle Spacing
60in
Tandem Oscillation - Front Up
15 degrees
Tandem Oscillation - Front Down
25 degrees
