Caterpillar 16H Motor Grader
Units
Dimensions
Dimensions
A
Overall Length
32.79ft in
B
Width Over Tires
10.08ft in
D
Wheelbase
22.83ft in
E
Rear Ground Clearance
1.34ft in
G
Tandem Axle Wheelbase
6ft in
F
Front Ground Clearance
2.4ft in
H
Blade Base
10.08ft in
Height To Top Of Isomount Cab
11.58ft in
Specifications
Engine
Number Of Cylinders
6
Net Power Gear 4-6
285hp
Engine Make
2236
Engine Model
3196 ETA
Net Power Gear 1-2
265hp
Power Measured @
2000rpm
Net Power Gear 5-6
285hp
Max Power
285hp
Net Power Gears 7-8
285hp
Net Torque Gears 7-8
1143lb ft
Displacement
726cu in
Operational
Std Operation Weight - Front Axle
15397lb
Std Operation Weight - Rear Axle
39153lb
Hydraulic System Fluid Capacity
34gal
Std Operation Weight - Total
54550lb
Max Operation Weight - Front Axle
19502lb
Max Operation Weight - Rear Axle
50146lb
Max Operation Weight - Total
69648lb
Fuel Capacity
130gal
Cooling System Fluid Capacity
12.3gal
Rear Diff/Final Drive Fluid Capacity
30.1gal
Circle Gearbox Fluid Capacity
2.1gal
Tandem Case Fluid Capacity (Each)
31.5gal
Operating Voltage
24V
Alternator Supplied Amperage
75amps
Steering
Articulation Angle
20degrees
Turning Radius
27ft in
Transmission
Transmission Type
direct drive, power shift, planetary
Number Of Gears - Forward
8
Number Of Gears - Reverse
8
Max Speed - Forward
29.9mph
Max Speed - Reverse
28.4mph
Front Axle
Wheel Lean
18degrees
Oscillation - Total
32degrees
Ground Clearance
2.4ft in
Moldboard
Moldboard Width
16ft in
Moldboard Height
31in
Moldboard Thickness
1in
Max Depth Of Cut
18.5in
Side Shift Left
25.6in
Side Shift Right
31.1in
Blade Pull At Max Weight
45131lb
Blade Down Pressure
34901.4lb
Hydraulic System
Pump Type
axial piston
Pump Flow
66gal/min
Relief Valve Pressure
3500psi
Circle
Diameter
71.8in
Shift Left
27.2in
Shift Right
22in
Max Reach Outside Tires - Left
91in
Max Reach Outside Tires - Right
91in
Max Lift Above Ground
16.5in
Blade Tip Angle - Front
40degrees
Blade Tip Angle - Rear
5degrees
