Caterpillar 228 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.61ft in
B
Width Over Tires
5.01ft in
E
Ground Clearance
8in
C
Height To Top Of Cab
6.4ft in
D
Wheelbase
3.24ft in
F
Length W/O Bucket
8.27ft in
G
Clearance At Max Lift And Dump
7.12ft in
H
Reach At Max Lift And Dump
22.05in
Wheel Base
3.24ft in
Bucket Pin Height - Carry Position
9in
Clearance At Maximum Lift And Dump
84in
Length - Without Bucket
99in
Bucket Pin Height - Maximum Lift
9.34ft in
Maximum Overall Height
146in
Height - Top Of Cab
6.42ft in
Bumper Overhang - Rear Axle
38in
Reach - Maximum Lift/Dump
20in
Turning Radius From Center - Inc Bucket
80.63in
Length - With Bucket On Ground
127in
Vehicle Width Over Tires
60in
Operating Specifications
Breakout Force - Tilt Cylinder
3907lb
Breakout Force - Lift Cylinder
3129lb
Rated Operating Capacity
1500lb
Rated Operating Capacity With Optional Counterweight
1600lb
Tipping Load
3000lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3034
Gross Power
58hp
Net Power
54hp
Power Measured @
2600rpm
Displacement
183cu in
Bore
3.9in
Stroke
4in
Engine Model
Cat 3034C
Net Flywheel Power
41hp
Operational
Operational Weight
6070lb
Fuel Capacity
17.2gal
Max Speed
6.9mph
Hydraulic System Fluid Capacity
14.6gal
Operating Speed
6.9mph
Loader
Operating Load Rating
1500lb
Tipping Angle
2800degrees
Bucket Capacity
0.6yd3
Weights
Operating Weight
5843lb
Hydraulic
Pump Flow Capacity
30.2gal/min
Hydraulic System
Loader Hydraulic Pressure
3300 psi
Loader Hydraulic Flow
30 gal/min
Hydraulic Flow
Standard flow
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
17gal
Hydraulic Tank
9.2gal
Engine Crankcase
1.8gal
Hydraulic System
14.5gal
Chain Box - Each Side
1.6gal
Cab
Rops
SAE J1040 MAY94 and ISO3471:1994
Fops
SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I
Fops Level Ii
SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional)
