Caterpillar 246C Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
12.11ft in
B
Width Over Tires
5.5ft in
E
Ground Clearance
8.81in
C
Height To Top Of Cab
6.83ft in
D
Wheelbase
4.07ft in
F
Length W/O Bucket
10.25ft in
G
Clearance At Max Lift And Dump
7.95ft in
H
Reach At Max Lift And Dump
23.6in
Length - Without Bucket
117.2in
Maximum Dump Angle
40 degrees
Maximum Overall Height
157.4in
Rack Back Angle - Maximum Height
85 degrees
Reach - Maximum Lift/Dump
23.6in
Maximum Reach - With Arms Parallel
54.6in
Bucket Pin Height - Carry Position
7.8in
Bucket Pin Height - Maximum Lift
10.25ft in
Bumper Overhang - Rear Axle
42.8in
Clearance At Maximum Lift And Dump
95.4in
Departure Angle
26 degrees
Height - Top Of Cab
6.9ft in
Length - With Bucket On Ground
145.31in
Turning Radius From Center - Inc Bucket
94.9in
Turning Radius From Center - Machine Rear
58.5in
Vehicle Width Over Tires
66in
Wheel Base
4.07ft in
Turn Radius From Center - Bucket
85.3in
Turn Radius From Center - Coupler
54.6in
Turn Radius From Center - Rear
68.1in
Operating Specifications
Rated Operating Capacity With Optional Counterweight
2350lb
Tipping Load
4300lb
Breakout Force - Tilt Cylinder
7328lb
Rated Operating Capacity
2150lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3044C DIT
Gross Power
74hp
Net Power
73hp
Power Measured @
2500rpm
Displacement
201cu in
Bore
3.7in
Stroke
4.7in
Gross Power - Sae J1995
74hp
Engine Model
Cat C3.4 DIT
Net Power - Sae 1349
73hp
Net Flywheel Power
73hp
Operational
Operational Weight
7381lb
Fuel Capacity
26gal
Cooling System Fluid Capacity
3.7gal
Engine Oil Fluid Capacity
2.6gal
Max Speed
7.7mph
Hydraulic System Fluid Capacity
15gal
Chain Box Fluid Capacity - Each Side
2.6gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Power Train
Travel Speed Forward
7.7mph
Travel Speed Reverse
7.7mph
Travel Speed Reverse - 2-Speed Option
12mph
Travel Speed Forward - 2-Speed Option
12mph
Loader
Breakout Force
7328lb
Operating Load Rating
2150lb
Tipping Angle
4300degrees
Bucket Capacity
0.5yd3
Weights
Operating Weight
7480lb
Hydraulic
Pump Flow Capacity
22gal/min
Relief Valve Pressure
3335psi
Hydraulic System
Hydraulic Flow (1)
Standard
Hydraulic Power
42.8hp
Maximum Loader Hydraulic Flow
33 gal/min
Maximum Loader Hydraulic Pressure
4061 psi
Loader Hydraulic Pressure
3335 psi
Loader Hydraulic Flow
22 gal/min
Hydraulic Flow (2)
High Flow XPS
Service Refill Capacities
Cooling System
3.7gal
Fuel Tank
26gal
Hydraulic Tank
11gal
Engine Crankcase
2.6gal
Hydraulic System
15gal
Chain Box - Each Side
2.6gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J1043 SEPT87, ISO 3449:1992 Level I
Fops Level Ii
SAE J231 JAN81, ISO 3449:1992 Level II
