Caterpillar 257 Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.5ft in
C
Height To Top Of Cab
6.64ft in
E
Ground Clearance
10.12in
G
Clearance At Max Lift And Dump
7.47ft in
H
Reach At Max Lift And Dump
2.62ft in
Length With Bucket
11.55ft in
Length With Out Bucket
8.87ft in
Turning Radius From Center - Inc Bucket
90.28in
Undercarriage
D
Length Of Track On Ground
4.92ft in
Width Of Track
15in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3034T
Gross Power
63hp
Net Power
59hp
Power Measured @
2600rpm
Displacement
183cu in
Bore
3.9in
Stroke
4in
Aspiration
Turbocharged
Engine Model
Cat 3034 naturally aspirated
Operational
Operating Weight
7676lb
Fuel Capacity
23.8gal
Hydraulic System Fluid Capacity
14.6gal
Max Speed - High Range
7mph
Power Train
Travel Speed Forward
7.5mph
Travel Speed Reverse
7.5mph
Loader
Operating Load
2350lb
Tipping Angle
4473degrees
Bucket Capacity
0.6yd3
Weights
Operating Weight
7628lb
Hydraulic
Pump Flow
15.2gal/min
Operating Specifications
Rated Operating Capacities - 50% Tipping Load
2306lb
Rated Operating Capacities - 35% Tipping Load
1614lb
Ground Contact Area
1770in2
Ground Pressure
4.3 psi
Tipping Load
4610lb
Breakout Force - Tilt Cylinder
3532lb
Breakout Force - Lift Cylinder
3490lb
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
23.8gal
Hydraulic Tank
9.2gal
Engine Crankcase
1.8gal
Hydraulic System
14.5gal
