Caterpillar 287C Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
6.5ft in
C
Height To Top Of Cab
6.94ft in
E
Ground Clearance
8.81in
G
Clearance At Max Lift And Dump
8.04ft in
H
Reach At Max Lift And Dump
2.58ft in
Height - Top Of Cab
6.94ft in
Length - Track On Ground
71.2in
Length - With Bucket On Ground
145.4in
Length - Without Bucket
117.2in
Length With Bucket
12.12ft in
Bucket Pin Height - Maximum Lift
10.61ft in
Bucket Pin Reach - Maximum Lift
14.7in
Clearance At Maximum Lift And Dump
96.5in
Departure Angle
42 degrees
Turning Radius From Center - Inc Bucket
91.74in
Turning Radius From Center - Machine Rear
64.06in
Vehicle Width
78in
Bucket Pin Height - Carry Position
7.8in
Length With Out Bucket
9.76ft in
Maximum Dump Angle
50 degrees
Maximum Overall Height
160.4in
Maximum Reach - With Arms Parallel
50.6in
Overall Length - Track
90in
Rack Back Angle - Maximum Height
85 degrees
Reach At Maximum Lift/Dump
30.9in
Turn Radius From Center - Bucket
91.7in
Turn Radius From Center - Coupler
58.5in
Turn Radius From Center - Rear
64in
Undercarriage
D
Length Of Track On Ground
5.94ft in
Ground Contact Area
2542in2
Ground Pressure
3.91psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
C3.4 DIT
Gross Power
84hp
Net Power
82hp
Power Measured @
2500rpm
Displacement
201cu in
Bore
3.7in
Stroke
4.7in
Gross Power - Sae J1995
84hp
Engine Model
Cat C3.4 DIT
Engine Power - Iso 14396
83hp
Net Power - Eec 80/1269
83hp
Net Power - Iso 9249 Eec
83hp
Net Power - Sae 1349
82hp
Operational
Operating Weight
9958lb
Cooling System Fluid Capacity
3.7gal
Fuel Capacity
25.9gal
Engine Oil Capacity
2.7gal
Hydraulic System Fluid Capacity
15.1gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Max Speed - Low Range
5.6mph
Max Speed - High Range
9.3mph
Power Train
Travel Speed Forward
5.6mph
Travel Speed Reverse
5.6mph
Travel Speed Reverse - 2-Speed Option
9.3mph
Travel Speed Forward - 2-Speed Option
9.3mph
Loader
Breakout Force
7308lb
Operating Load
3800lb
Tipping Angle
7743degrees
Weights
Operating Weight
9958lb
Hydraulic
Pump Flow
22.2gal/min
Relief Valve Pressure
3335.9psi
Hydraulic System
Hydraulic Flow (1)
Standard
Hydraulic Power
42.8hp
Maximum Loader Hydraulic Flow
33 gal/min
Maximum Loader Hydraulic Pressure
4061 psi
Loader Hydraulic Pressure
3335 psi
Loader Hydraulic Flow
22 gal/min
Hydraulic Flow (2)
High Flow XPS
Operating Specifications
Rated Operating Capacities - 50% Tipping Load
3800lb
Rated Operating Capacities - 35% Tipping Load
2709lb
Ground Contact Area
2542in2
Ground Pressure
3.9 psi
Rated Operating Capacity With Optional Counterweight
4118lb
Tipping Load
7743lb
Breakout Force - Tilt Cylinder
7308lb
Service Refill Capacities
Cooling System
3.7gal
Fuel Tank
26gal
Hydraulic Tank
11gal
Engine Crankcase
2.6gal
Hydraulic System
15gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J1043 SEPT87, ISO 3449:1992 Level I
Fops Level Ii
SAE J231 JAN81, ISO 3449:1992 Level II
