Caterpillar 323D L Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
31.86ft in
Shipping Height Of Unit
10.18ft in
Max Cutting Height
29.34ft in
Max Loading Height
19.66ft in
Max Reach Along Ground
29.47ft in
Max Vertical Wall Digging Depth
12.28ft in
Max Digging Depth
18.97ft in
Boom/Stick Option (Hex) 1
Boom 5680mm / Stick 1900mm
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
31.04ft in
Max Cutting Height
30.78ft in
Shipping Height Of Unit
10.01ft in
Max Loading Height
21.63ft in
Max Reach Along Ground
30.98ft in
Max Vertical Wall Digging Depth
16.7ft in
Max Digging Depth
20.35ft in
Boom/Stick Option (Hex) 2
Boom 5680mm / Stick 2500mm
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
31.04ft in
Max Cutting Height
31.44ft in
Max Loading Height
22.22ft in
Shipping Height Of Unit
9.95ft in
Max Reach Along Ground
32.35ft in
Max Vertical Wall Digging Depth
18.12ft in
Max Digging Depth
21.82ft in
Boom/Stick Option (Hex) 3
Boom 5680mm / Stick 2920mm
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
30.39ft in
Shipping Height Of Unit
10.34ft in
Max Cutting Height
28.58ft in
Max Loading Height
18.74ft in
Max Reach Along Ground
27.96ft in
Max Digging Depth
17.49ft in
Max Vertical Wall Dig Depth
11.72ft in
Boom/Stick Option (Hex) 4
Mass Boom 5200mm / Stick 1900mm
Dimensions
Ground Clearance
1.51ft in
Height To Top Of Cab
10.01ft in
Width To Outside Of Tracks
10.44ft in
Length Of Track On Ground
11.98ft in
Tail Swing Radius
9.03ft in
Removal Counterweight Clearance
3.35ft in
Undercarriage
Track Gauge
7.81ft in
Shoe Size
23.63in
Ground Pressure
6.67psi
Drawbar Pull
46310.64lb
Max Travel Speed
3.42mph
Specifications
Engine
Engine Make
2236
Engine Model
3066 ATAAC
Net Power
140hp
Power Measured @
1800rpm
Aspiration
Turbocharged
Displacement
389cu in
Bore
4.1in
Stroke
5.2in
Net Power - Iso 9249
150hp
Engine Model
Cat C6.4 ACERT
Net Power - Eec 80/1269
150hp
Net Flywheel Power
150hp
Operational
Operating Weight
48193.1lb
Fuel Capacity
84.6gal
Cooling System Fluid Capacity
6.7gal
Hydraulic System Fluid Capacity
68.7gal
Engine Oil Capacity
8gal
Operating Voltage
24V
Swing Drive Fluid Capacity
2.2gal
Alternator Supplied Amperage
80amps
Hydraulic System Relief Valve Pressure
5076.4psi
Hydraulic Pump Flow Capacity
108.4gal/min
Swing Mechanism
Swing Torque
45600lb ft
Swing Speed
11.5rpm
Weights
Operating Weight
50706lb
Operating Weight - Maximum
50926lb
Operating Weight - Minimum
49163lb
Buckets
Reference Bucket Capacity
1.5yd3
Hydraulic System
Pilot System - Maximum Flow
8.6 gal/min
Pilot System - Maximum Pressure
566 psi
Maximum Pressure - Travel
5076 psi
Maximum Pressure - Swing
3626 psi
Main Implement System - Maximum Flow (2x)
54 gal/min
Boom Cylinder - Bore
4.7in
Boom Cylinder - Stroke
49.6in
Stick Cylinder - Bore
5.5in
Stick Cylinder - Stroke
59.2in
Maximum Pressure - Equipment
5076 psi
B1 Family Bucket Cylinder - Bore
4.7in
B1 Family Bucket Cylinder - Stroke
43.5in
Maximum Pressure - Normal
5076.32 psi
Service Refill Capacities
Cooling System
6.6gal
Final Drive - Each
2.6gal
Hydraulic Tank
32gal
Hydraulic System - Including Tank
69gal
Engine Oil
8gal
Fuel Tank Capacity
108gal
Swing Drive
2.1gal
Standards
Brakes
SAE J1026 APR90
Cab/Fogs
SAE J1356 FEB88
Sound Performance
Performance
ANSI/SAE J1166 OCT 98
Drive
Maximum Travel Speed
3.5mph
Maximum Drawbar Pull
46310lb
