Caterpillar 325B L Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
33.76ft in
Shipping Height Of Unit
10.73ft in
Max Cutting Height
32.68ft in
Max Loading Height
23.33ft in
Max Reach Along Ground
34.52ft in
Max Vertical Wall Digging Depth
20.94ft in
Max Digging Depth
23.27ft in
Boom/Stick Option (Hex) 1
Boom 20\'2\" (6150mm) / Stick 10\'6\" (3200mm)
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
33.76ft in
Max Cutting Height
31.7ft in
Shipping Height Of Unit
10.73ft in
Max Loading Height
22.64ft in
Max Reach Along Ground
32.85ft in
Max Vertical Wall Digging Depth
16.9ft in
Max Digging Depth
21.46ft in
Boom/Stick Option (Hex) 2
Boom 20\'2\" (6150mm) / Stick 8\'8\" (2700mm)
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
31.86ft in
Max Cutting Height
29.96ft in
Max Loading Height
20.02ft in
Shipping Height Of Unit
11.36ft in
Max Reach Along Ground
30.68ft in
Max Vertical Wall Digging Depth
14.8ft in
Max Digging Depth
19.72ft in
Boom/Stick Option (Hex) 3
Mass Boom 18\'3\" (5550mm) / Stick 8\'2\" (2500mm)
Dimensions
Ground Clearance
1.68ft in
Height To Top Of Cab
10.14ft in
Width To Outside Of Tracks
11.13ft in
Length Of Track On Ground
12.46ft in
Tail Swing Radius
10.01ft in
Removal Counterweight Clearance
3.75ft in
Undercarriage
Track Gauge
8.5ft in
Shoe Size
31.5in
Drawbar Pull
48333.92lb
Max Travel Speed
3.11mph
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3116TA
Gross Power
177hp
Net Power
168hp
Power Measured @
2000rpm
Displacement
403cu in
Aspiration
Turbocharged and Aftercooled
Bore
4.2in
Stroke
5in
Net Power - Iso 9249
168hp
Net Power - Sae J1349
168hp
Engine Model
Cat 3116TA
Net Power - Eec 80/1269
168hp
Net Flywheel Power
168hp
Operational
Operating Weight
60600lb
Fuel Capacity
111gal
Cooling System Fluid Capacity
8.4gal
Hydraulic System Fluid Capacity
81.9gal
Engine Oil Capacity
5.3gal
Operating Voltage
24V
Swing Drive Fluid Capacity
2.7gal
Alternator Supplied Amperage
52amps
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
109.9gal/min
Swing Mechanism
Swing Torque
56080lb ft
Weights
Operating Weight - Standard Undercarriage
56240lb
Buckets
Reference Bucket Capacity
1.5yd3
Minimum Bucket Capacity
1.4yd3
Maximum Bucket Capacity
2.5yd3
Hydraulic System
Pilot System - Maximum Flow
10.8 gal/min
Pilot System - Maximum Pressure
595 psi
Maximum Pressure - Travel
4980 psi
Maximum Pressure - Swing
4250 psi
Main Implement System - Maximum Flow (2x)
56.5 gal/min
Boom Cylinder - Bore
5.5in
Boom Cylinder - Stroke
55in
Maximum Pressure - Equipment
4980 psi
C Family Bucket Cylinder - Bore
5.2in
C Family Bucket Cylinder - Stroke
46in
D Family Bucket Cylinder - Bore
6in
D Family Bucket Cylinder - Stroke
46in
Service Refill Capacities
Cooling System
8.3gal
Final Drive - Each
2.1gal
Hydraulic System - Including Tank
82gal
Engine Oil
5.3gal
Fuel Tank Capacity
111gal
Swing Drive
2.6gal
Track
Standard With Standard Undercarriage
24in
Optional (1)
24in
Optional (2)
28in
Optional (3)
32in
Standard With Long Undercarriage - Triple Grouser
32in
Drive
Maximum Travel Speed
3.1mph
Maximum Drawbar Pull
48350lb
