Caterpillar 349F L XE Hydraulic Excavator
Specifications
Engine
Displacement
763cu in
Bore
5.2in
Stroke
6.2in
Net Power - Sae J1349
417hp
Gross Power - Sae J1995
432hp
Engine Model
Cat C13 ACERT
Net Flywheel Power
417hp
Operational
Operating Weight
113600lb
Swing Mechanism
Swing Speed
8.5rpm
Swing Torque
109500lb ft
Weights
Note
Long FIX undercarriage, 6.9 m (22'8") reach boom, R3.35TB HD (11'0") HD stick, 9.0 mt (9.9 t) counterweight, Long FIX undercarriage, 3.1 m3 (4.1 yd3) bucket, 600 mm (24") double grouser shoes.
Maximum Weight
113600lb
Minimum Weight
108300lb
Hydraulic System
Pilot System - Maximum Flow
6.9 gal/min
Pilot System - Maximum Pressure
598 psi
Maximum Pressure - Travel
5080 psi
Maximum Pressure - Swing
3990 psi
Swing System - Maximum Flow
99 gal/min
Boom Cylinder - Bore
6.7in
Boom Cylinder - Stroke
60in
Stick Cylinder - Bore
7.5in
Stick Cylinder - Stroke
69.3in
Main System - Maximum Flow - Total
198 gal/min
Maximum Pressure - Equipment
5080 psi
Maximum Pressure - Equipment - Lift Mode
5510 psi
Tb Family Bucket Cylinder - Stroke
53.4in
Tb Family Bucket Cylinder - Bore
6.3in
Service Refill Capacities
Cooling System
13.2gal
Def Tank
10.8gal
Final Drive - Each
4gal
Hydraulic Tank
108gal
Hydraulic System - Including Tank
151gal
Note
Diesel exhaust fluid (DEF) must meet requirements outlined in ISO 22241.
Fuel Tank Capacity
190gal
Swing Drive - Each
2.6gal
Engine Oil - With Filter
10gal
Standards
Cab - Rops
ISO 12117-2
Brakes
ISO 10265
Cab/Fogs
SAE J1356
Sound Performance
Operator Noise (Closed) - Iso 6396
69 dB(A)
Spectator Noise - Iso 6395
106 dB(A)
Note (1)
When properly installed and maintained, the cab offered by Caterpillar, when tested with doors and windows closed according to ANSI/SAE J1166 OCT98, meets OSHA and MSHA requirements for operator sound exposure limits in effect at time of manufacture.
Note (2)
Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in noisy environment.
Track
Number Of Shoes - Each Side - Long Fix Undercarriage
52
Number Of Track Rollers - Each Side - Long Fix Undercarriage
9
Number Of Carrier Rollers - Each Side - Long Fix Undercarriage
2
Drive
Maximum Travel Speed
2.9mph
Maximum Drawbar Pull
75300lb
