Caterpillar 390F L Hydraulic Excavator
Units
Dimensions
Dimensions
E
Ground Clearance
2.96ft in
G
Height To Top Of Cab
12.57ft in
B
Width To Outside Of Tracks
9.03ft in
D
Length Of Track On Ground
20.86ft in
H
Tail Swing Radius
15.42ft in
Removal Counterweight Clearance
5.39ft in
Undercarriage
Number Of Carrier Rollers Per Side
3
Max Travel Speed
2.8mph
Drawbar Pull
132637lb
Number Of Shoes Per Side
51
Number Of Track Rollers Per Side
9
Specifications
Engine
Engine Make
2236
Engine Model
C18 ACERT
Net Power
524hp
Displacement
1104.5cu in
Bore
5.7in
Stroke
7.2in
Net Power - Sae J1349
524hp
Engine Model
Cat C18 ACERT
Net Flywheel Power
524hp
Engine Rpm - Operation
1700rpm
Engine Rpm - Travel
1900rpm
Operational
Operating Weight
190204lb
Fuel Capacity
328327.6gal
Cooling System Fluid Capacity
20gal
Hydraulic System Fluid Capacity
263gal
Engine Oil Capacity
16gal
Swing Drive Fluid Capacity
5gal
Hydraulic Pump Flow Capacity
266gal/min
Swing Mechanism
Swing Speed
6.2rpm
Swing Torque
191766lb ft
Weights
Operating Weight
190204lb
Maximum Operating Weight
190204lb
Minimum Operating Weight
156461lb
Hydraulic System
Pilot System - Maximum Flow
17.7 gal/min
Pilot System - Maximum Pressure
4.0-4.4 MPa (580-638 psi)
Maximum Pressure - Travel
5076 psi
Maximum Pressure - Swing
3770 psi
Swing System - Maximum Flow
No swing pump
Boom Cylinder - Bore
8.3in
Boom Cylinder - Stroke
77in
Stick Cylinder - Bore
8.7in
Stick Cylinder - Stroke
89in
Maximum Pressure - Equipment - Normal
5076 psi
Hb2 Family Bucket Cylinder - Bore
7.9in
Hb2 Family Bucket Cylinder - Stroke
57in
Jc Family Bucket Cylinder - Bore
8.7in
Jc Family Bucket Cylinder - Stroke
62in
Main System - Maximum Flow - Total - Implement
266 gal/min
Main System - Maximum Flow - Total - Travel
281 gal/min
Main System - Maximum Flow ( 2 Pumps) - Implement
133 gal/min
Main System - Maximum Flow ( 2 Pumps) - Travel
141 gal/min
Service Refill Capacities
Cooling System
20gal
Def Tank
13gal
Final Drive - Each
5.5gal
Hydraulic Tank
215gal
Hydraulic System - Including Tank
263gal
Engine Oil
16gal
Fuel Tank Capacity
328gal
Swing Drive - Each
5gal
Standards
Brakes
SAE J1026 APR90
Cab/Fogs
SAE J1356 FEB88 ISO 10262
Sound Performance
Iso 6395 - Exterior
109 dB(A)
Iso 6396 - Inside Cab
74 dB(A)
Track
Number Of Carrier Rollers - Each Side
3
Number Of Track Rollers - Each Side - Long Undercarriage
9
Number Of Shoes - Each Side - Long Undercarriage
51
Optional For Long Undercarriage (1)
26in
Optional For Long Undercarriage (2)
30in
Standard With Long Undercarriage
35in
Drive
Maximum Travel Speed
2.8mph
Maximum Drawbar Pull
132637lb
Maximum Drawbar Pull - Long Undercarriage
132637lb
