Caterpillar 572R Crawler Pipe Layer
Units
Dimensions
Boom
Lift Capacity At Max Reach
90000lb
Boom Length
20.02ft in
Dimensions
A
Overall Length
15.54ft in
B
Overall Width
12.01ft in
G
Width Over Tracks
9.5ft in
C
Overall Height
22.08ft in
D
Length Of Track On Ground
10.42ft in
E
Ground Clearance
1.37ft in
Shipping Width
12ft in
Height To Top Of Suspended Cab
9.5ft in
Length
15.5ft in
Shipping Height
11.25ft in
Specifications
Engine
Engine Make
2236
Engine Model
3176C
Net Power
240.1hp
Gross Power
257.5hp
Displacement
628.6cu in
Net Power - Iso 9249
230hp
Engine Model
3306
Flywheel Power
230hp
Operational
Operating Weight
70206.3lb
Fuel Capacity
126.6gal
Cooling System Fluid Capacity
20.5gal
Final Drives Fluid Capacity
3.5gal
Transmission
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.6mph
Max Speed - Reverse
8.5mph
Weights
Operating Weight
64170lb
Hydraulic System
Pump Type
Pressure compensating piston-type pump.
Pipelaying Equipment
Lift Capacity
90000lb
