Caterpillar 725C Articulated Dump Truck
Units
Dimensions
Dump
H
Dump Angle
45degrees
Rated Payload
23586.8lb
Capacity - Heaped
20.4yd3
Capacity - Struck
14.4yd3
Lower Time
8sec
Raise Time
10sec
Specifications
Engine
Engine Make
2236
Engine Model
C9.3 Acert
Gross Power
320hp
Net Power
314hp
Max Torque
1263lb ft
Torque Measured @
1200rpm
Displacement
567cu in
Operational
Fuel Capacity
28.6gal
Hydraulic System Fluid Capacity
7.7gal
Cooling System Fluid Capacity
5.8gal
Engine Oil Capacity
2.7gal
Transmission Fluid Capacity
3.3gal
Transmission
Number Of Forward Gears
6
Number Of Reverse Gears
1
Weights
Center Axle - Empty
10030%
Front Axle - Empty
31813lb
Rear Axle - Empty
9348lb
Front Axle - Loaded
5423%
Center Axle - Loaded
23303%
Rear Axle - Loaded
23303lb
Total Empty
51191lb
Total Loaded
103220lb
