Caterpillar 735 Articulated Dump Truck

Units

Dimensions

Overall Length

35.73ft in

Overall Width

11.01ft in

Overall Height

12.15ft in

Wheelbase

17.15ft in

Ground Clearance

1.76ft in

Dump Height

22.82ft in

Dump Ground Clearance

2.09ft in

Wheel Base Between Back Tires

6.4ft in

Dump Clearance

2ft in

Dump

Lower Time

7sec

Capacity - Heaped

25.77yd3

Capacity - Struck

19.23yd3

Rated Payload

72091.16lb

Raise Time

11sec

Specifications

Engine

Number Of Cylinders

Engine Make

2236

Engine Model

C15 with ACERT Technology

Gross Power

413hp

Net Power

394hp

Max Torque

1524.6lb ft

Torque Measured @

1200rpm

Aspiration

Turbocharged

Displacement

926cu in

Bore

5.4in

Stroke

6.8in

Emissions

The 735 meets Tier 4 Final/Stage IV emission standards.

Net Power - Iso 9249

424hp

Net Power - Sae J1349

419hp

Gross Power - Sae J1995

435hp

Engine Model

Cat C15 ACERT

Flywheel Power

385hp

Net Power - Iso 14396

429hp

Note (1)

The references to Tier 4 Final/Stage IV include U.S. EPA Tier 4 Final, EU Stage IV, Japan 2014 (Tier 4 Final), and Korea Tier 4 Final emission standards.

Note (2)

The power ratings apply at rated speed of 1,800 rpm when tested under the conditions for the specified standard.

Note (3)

The net power advertised is the power available at the flywheel when the engine is equipped with alternator, air cleaner, muffler and fan at minimum speed.

Note (4)

Net power when the fan is at maximum speed is 254 kW (341 hp) per the SAE reference conditions.

Net Power - Eec 80/1269

424hp

Note (5)

DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1. ISO 22241-1 requirements are met by many brands of DEF, including those that carry the AdBlue or API certifications.

Peak Engine Torque Gross (Sae J1995)

1614lb ft

Peak Engine Torque Speed

1200rpm

Engine Model - U.S. Epa Tier 4 Final/Eu Stage Iv

Cat C13 ACERT

Peak Engine Torque Net (Sae J1349)

1597lb ft

No Engine De-Rating Below

12500ft in

Operational

Fuel Capacity

148gal

Hydraulic System Fluid Capacity

61.6gal

Cooling System Fluid Capacity

21.2gal

Engine Oil Capacity

10.1gal

Transmission Fluid Capacity

19.1gal

Tire Size

26.5R25

Transmission

Number Of Forward Gears

Number Of Reverse Gears

Max Speed

36.3mph

Forward - 1

5.2mph

Forward - 2

7.1mph

Forward - 3

9.6mph

Forward - 4

12.9mph

Forward - 5

17.5mph

Forward - 6

23.5mph

Forward - 7

31.9mph

Reverse - 1

5mph

Reverse - 2

6.8mph

Steering

Lock To Lock

4.75 seconds @ 60 rpm

Weights

Center Axle - Empty

14087.6%

Front Axle - Empty

40014lb

Rear Axle - Empty

12588.4lb

Front Axle - Loaded

48479.7%

Center Axle - Loaded

45900.3%

Rear Axle - Loaded

44401.2lb

Total Empty

66689.9lb

Total Loaded

138781.1lb

Service Refill Capacities

Cooling System

25.1gal

Fuel Tank

148gal

Def Tank

5.3gal

Engine Crankcase

10.6gal

Transmission

22.5gal

Hydraulic System

86.6gal

Final Drives/Differential

21.1gal

Output Transfer Gear Box

6.3gal

Standards

Cab - Fops

SAE J231 JAN81 and ISO 3449-1992 Level II

Cab - Rops

SAE J1040 May 1994 and ISO 3471-1994

Brakes

SAE J/ISO 3450-1998

Steering

ISO 5010 1992E

Operating Weights

Front Axle - Empty

41881lb

Center Axle - Empty

14406lb

Rear Axle - Empty

12919lb

Total - Empty

69206lb

Front Axle - Rated Load

7417lb

Center Axle - Rated Load

32337lb

Rear Axle - Rated Load

32337lb

Total - Rated Load

72091lb

Front Axle - Loaded

49298lb

Center Axle - Loaded

46743lb

Rear Axle - Loaded

45256lb

Total - Loaded

141297lb

Sound Levels

Interior Cab

79 dB(A)

Note (1)

The operator sound exposure Leq (equivalent sound pressure level) measured according to the work cycle procedures specified in ANSI/SAE J1166 OCT98 is 72 dB(A), for the cab offered by Caterpillar, when properly installed and maintained and tested with the doors and windows closed.

Note (2)

Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in noisy environments.

Turning Circle

Note

Dimensions are for machines equipped with 750/65 R25 tires.

Turning Dimensions - Sae Turning Radius

294in

Turning Dimensions - Clearance Radius

318in

Turning Dimensions - Inside Radius

149in

Turning Dimensions - Aisle Width

212in

Body Capacities

Heaped (Sae 2:1)

25.8yd3

Struck

19yd3

Tailgate Struck

19.9yd3

Tailgate Heaped Sae 2:1

27.3yd3

Heaped Sae 1:1

32yd3

Body Hoist

Raise Time

11 s

Lower Time

7 s

Body Plate Thickness

Front

0.4in

Scow

0.6in

Side

0.5in

Base

0.6in

Front Plate

0.3in

Base Plate

0.6in

Side Plates

0.5in

Body Plate

Body Plate Type

High strength Brinell HB450 wear resistant steel

Optimal Loader/Truck Pass Matching

Note

An optimum system match gives you a major productivity advantage. The 735 is an excellent match for the Cat 349F and 336F Hydraulic Excavators; and Cat 972M, 966M, 962M and 950M Wheel Loaders. Having matched loading and hauling tools results in increased production and lower system costs per unit of volume moved.
