Caterpillar 816B Compactor
Units
Dimensions
Dimensions
A
Length With Blade On Ground
23.2ft in
E
Ground Clearance
1.61ft in
B
Width Over Wheels
10.96ft in
C
Height To Top Of Cab
13.26ft in
D
Wheelbase
11ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3306
Net Power
216hp
Gross Power
235hp
Power Measured @
2200rpm
Displacement
640.8cu in
Aspiration
turbocharged
Operational
Operating Weight
45792.3lb
Fuel Capacity
122.1gal
Hydraulic System Fluid Capacity
35.4gal
Engine Oil Capacity
7.7gal
Cooling System Fluid Capacity
11.7gal
Transmission Fluid Capacity
15.9gal
Operating Voltage
24V
Alternator Supplied Amperage
50amps
Transmission
Transmission Type
Cat. Planetary powershift
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed
22mph
Wheels
Front Wheels Drum Width
40in
Front Wheels Drum Diameter
51.2in
Rear Wheels Drum Width
40in
Rear Wheels Drum Diameter
51.2in
Blade
Height
75.4in
Width
12ft in
