Caterpillar 907M Ag Handler Wheel Loader
Dimensions
Dimensions - With Iso Coupler - Approximate
Width - Tread Center
4.58ft in
Note
Dimensions shown are based on the machine equipped with general purpose bucket and standard 340/80 R18, MX, XMCL tires.
Articulation Angle
39 degrees
Clearance - Bucket At 45 Degrees
8.08ft in
Clearance - Full Lift
9.92ft in
Clearance - Level Arm
4.42ft in
Clearance - Level Bucket
9.83ft in
Departure Angle
33 degrees
Dig Depth
4.2in
Dump Angle At Full Lift
45 degrees
Fork Dig Depth
3.1in
Fork Reach At Full Lift
1.42ft in
Height - Bucket Pin
10.5ft in
Height - Ground Clearance
11in
Height - Ground To Cab
8.33ft in
Length - Overall With Bucket
17.68ft in
Length - Overall With Forks
19.43ft in
Length - Wheel Base
7.08ft in
Reach - Bucket At 45 Degrees
2.42ft in
Reach - Ground
2.42ft in
Reach - Level Arm
4ft in
Turning Radius - Inside Tire
6.83ft in
Turning Radius - Over Bucket
14.67ft in
Width - Bucket
6.67ft in
Width - Over Tires
6ft in
Dimensions - With Ssl Coupler - Approximate
Reach - Level Arm
4.17ft in
Width - Tread Center
4.58ft in
Articulation Angle
39 degrees
Height - Ground To Cab
8.33ft in
Length - Overall With Bucket
18.18ft in
Clearance - Bucket At 45 Degrees
7.75ft in
Clearance - Full Lift
10.17ft in
Turning Radius - Inside Tire
6.83ft in
Clearance - Level Arm
4.67ft in
Width - Over Tires
6ft in
Clearance - Level Bucket
9.83ft in
Length - Overall With Forks
19.43ft in
Departure Angle
33 degrees
Length - Wheel Base
7.08ft in
Dig Depth
4.5in
Turning Radius - Over Bucket
14.75ft in
Reach - Bucket At 45 Degrees
2.75ft in
Dump Angle At Full Lift
43 degrees
Fork Dig Depth
0.2in
Note
Dimensions shown are based on the machine equipped with general purpose bucket and standard 340/80 R18, MX, XMCL tires.
Fork Reach At Full Lift
1.67ft in
Reach - Ground
2.42ft in
Height - Bucket Pin
10.5ft in
Width - Bucket
6.67ft in
Height - Ground Clearance
11in
Specifications
Engine
Emissions
*The Cat C3.3B DIT engine meets U.S. EPA Tier 4 Final/EU Stage IIIB emission standards.
Maximum Gross Power - Sae J1995
74hp
Maximum Net Power - Sae J1349
68hp
Maximum Gross Power - Iso 14396
73hp
Rated Net Power - 2,500 Rpm - Sae J1349
68hp
Maximum Net Power - Iso 9249
69hp
Maximum Gross Power
73hp
Operational
Operating Weight
12958lb
Weights
Operating Weight
12958lb
Note
Machine with full fuel tank, ROPS/FOPS cab, 80 kg (176 lb) operator, skid steer loader coupler (SSL) and general purpose bucket (GP).
Buckets
Bucket Capacities
ISO Coupler - 0.75-1.2 m; SSL Style Coupler - 1.0-1.6 yd
Bucket Capacities - Iso Coupler
0.75-1.2 m
Bucket Capacities - Ssl Style Coupler
1.0-1.6 yd
Hydraulic System
Hydraulic Cycle Time - Dump
1.3 seconds
Main Relief - 3rd Aux Flow: Standard
20 gal/min
Main Relief - 3rd Aux Flow
3400 psi
Main Relief - 3rd Aux Flow: High Flow
31 gal/min
Hydraulic Cycle Time - Lift
5.2 seconds
Hydraulic Cycle Time - Rackback
2.1 seconds
Hydraulic Cycle Time - Lower
3.2 seconds
Service Refill Capacities
Cooling System
4.5gal
Fuel Tank
20.6gal
Hydraulic System
18.5gal
Engine Oil
3gal
Maximum Material Densities - General Purpose Bucket
Bucket Width
80in
Maximum Material Density
3031 lb/yd
Rated Capacity
1.2yd3
Dump Height
97in
Note
Based on ISO 7546:1983, and rated operating loads at full turn with 100% bucket capacity and SSL coupler.
Maximum Material Densities - Light Material Bucket
Bucket Width
82in
Maximum Material Density
2363 lb/yd
Rated Capacity
1.6yd3
Dump Height
85in
Note
Based on ISO 7546:1983, and rated operating loads at full turn with 100% bucket capacity and SSL coupler.
Maximum Material Densities - Multi Purpose Bucket
Bucket Width
74in
Maximum Material Density
3460 lb/yd
Rated Capacity
1yd3
Dump Height
85in
Note
Based on ISO 7546:1983, and rated operating loads at full turn with 100% bucket capacity and SSL coupler.
Operating Specifications - Iso Coupler
Rated Bucket Capacity
1.2yd3
Rated Operating Load At Full Turn - Bucket
4019lb
Tire Size
340/80 R18
Straight Tipping Load - Bucket
9531lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 1.25 Stability And 500 Mm [20 In] Load Center)
5226lb
Breakout Force - Bucket
11240lb ft
Full Turn Static Tipping Load - Bucket
8038lb
Rack Back - Transport Position
52 degrees
Note
Machine with full fuel tank, ROPS/FOPS cab, 80 kg (176 lb) operator, ISO coupler and general purpose bucket (GP).
Operating Specifications - Ssl Coupler
Rated Bucket Capacity
1.2yd3
Rated Operating Load At Full Turn - Bucket
3763lb
Tire Size
340/80 R18
Straight Tipping Load - Bucket
8946lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 1.25 Stability And 500 Mm [20 In] Load Center)
4974lb
Breakout Force - Bucket
8983lb ft
Full Turn Static Tipping Load - Bucket
7529lb
Rack Back - Transport Position
53 degrees
Note
Machine with full fuel tank, ROPS/FOPS cab, 80 kg (176 lb) operator, SSL coupler and general purpose bucket (GP).
Travel Speeds
Speed 1
6.2mph
Speed 2
12.4mph
High Speed
21.7mph
