Caterpillar 908H2 Wheel Loader
Units
Dimensions
Dimensions
E
Ground Clearance
1.09ft in
Cab Height
8.69ft in
Departure Angle - Degrees
34degrees
Dig Depth
3.7in
Dump Angle At Maximum Height - Degrees
45degrees
Fork Depth Below Ground
1.2in
Fork Height At Maximum Reach
5ft in
Fork Reach At Maximum Height
1.95ft in
Hinge Pin At Maximum Height
11.19ft in
Load Over Height
10.55ft in
Machine Width
6.51ft in
Maximum Dump Height
8.33ft in
Maximum Fork Height
10.83ft in
Maximum Reach
4.74ft in
Overall Length - With Bucket
18.9ft in
Overall Length - With Forks
20.18ft in
Reach At Ground Level
3ft in
Reach At Maximum Dump Height
2.81ft in
Tire Gauge
5.15ft in
Turning Radius - Inside Tire
6.82ft in
Turning Radius - Over Bucket
15ft in
Wheel Base
7.12ft in
Articulation Angle - Degrees
39degrees
Width - Over Bucket
6.76ft in
Specifications
Engine
Net Power
69hp
Displacement
203cu in
Bore
3.7in
Stroke
4.7in
Maximum Gross Power - Sae J1995
74hp
Maximum Net Power - Sae J1349
68hp
Maximum Gross Power - Iso 14396
73hp
Rated Net Power - 2,500 Rpm - Sae J1349
68hp
Maximum Net Power - Iso 9249
69hp
Gross Power - 2,500 Rpm - Sae J1995
74hp
Net Power - 2,500 Rpm - Sae J1349
68hp
Operational
Operating Weight
14253lb
Transmission
Travel Speed 1
4.3mph
Travel Speed 2
12.4mph
High Speed
21.7mph
Buckets
Bucket Capacities
0.9-1.5 m3 (1.2-2.0 yd3)
Hydraulic System
Hydraulic Cycle Time - Dump
2 Seconds
Hydraulic Cycle Time - Lift
5 Seconds
Hydraulic Cycle Time - Rackback
2.5 Seconds
Main Relief
3400 psi
Hydraulic Cycle Time - Lower, Float
4 Seconds
3rd Auxiliary Flow - Standard Flow
22 gal/min
3rd Auxiliary Flow - High Flow
33 gal/min
Operating Specifications
Breakout Force
10566lb
Rated Bucket Capacity
1.4yd3
Tire Size
405/70 R20
Full Turn Static Tipping Load - Bucket
7518lb
Rack Back - Transport Position
52degrees
Rated Operating Load At Full Turn - Bucket
3759lb
Hydraulic Lift Capacity
7868lb
Straight Tipping Load - Bucket
10527lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 500 Mm (20 In) Load Center, Transport 100 Mm (4 In) Above Ground)
6592lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 1.25 Stability And 500 Mm [20 In] Load Center)
5192lb
Rated Operating Load At Full Turn - Forks (Sae J1197, Load Center At Tine Mid-Point, 1120 Mm [44 In] Tines) (50% Ftstl)
3045lb
Rated Operating Load At Full Turn - Forks (Sae J1197, Load Center At Tine Mid-Point, 1220 Mm [48 In] Tines) (50% Ftstl)
2919lb
Rated Operating Load Straight Back - Forks (Sae J1197, Load Center At Tine Mid-Point, 1120 Mm [44 In] Tines) (50% Ftstl)
3907lb
Rated Operating Load Straight Back - Forks (Sae J1197, Load Center At Tine Mid-Point, 1220 Mm [48 In] Tines) (50% Ftstl)
3822lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 500 Mm [20 In] Load Center) (80% Of Ftstl)
5192lb
Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 500 Mm [20 In] Load Center) (60% Of Ftstl)
3893lb
Service Refill Capacities
Cooling System
6.3gal
Fuel Tank
20.6gal
Hydraulic System
25gal
Engine Oil
2.6gal
Cab
Rops
SAE J1040 MAY94, ISO 3471-1994
Fops
SAE J/ISO 3449 APR98 Level II, ISO 3449 1992 Level II
Maximum Material Densities - General Purpose
Rated Capacity
1.4yd3
Dump Height
100in
Maximum Material Density
2611 lb/yd
Bucket Width
81in
Maximum Material Densities - Light Material
Rated Capacity
2yd3
Dump Height
92in
Maximum Material Density
1743 lb/yd
Bucket Width
82in
Maximum Material Densities - Multi Purpose
Rated Capacity
1.2yd3
Dump Height
104in
Maximum Material Density
3251 lb/yd
Bucket Width
81in
Operator Environment Features - Canopy
Fixed Steering Column
Standard
Vinyl Suspension Seat
Standard
Coat Hook
Standard
Sun Visor
Standard
External Mirrors (2) - Knock Back
Standard
Lockable Storage Box
Standard
Adjustable Internal Mirror
Standard
Operator Environment Features - Comfort Cab
Two Access Doors
Standard
Adjustable Steering Column
Standard
Cloth Suspension Seat, Arm Rest
Standard
Left Window - Sliding
Standard
Heated Rear Window
Standard
Coat Hook
Standard
Cabin Light
Standard
Sun Visor
Standard
Radio-Ready Kit (Wiring, Speaker, Antenna And Grilles)
Standard
External Mirrors (2) - Knock Back
Standard
Heater
Standard
Lockable Storage Box
Standard
Adjustable Internal Mirror
Standard
Rear Blind
Optional
Cat Radio/Cd/Mp3/Wma Player
Optional
Operator Environment Features - Deluxe Cab
Two Access Doors
Standard
Heated Rear Window
Standard
Coat Hook
Standard
Cabin Light
Standard
Adjustable Steering Column
Standard
Cloth Electric Air Suspension Seat, Arm/Head Rest, Lumbar Support, Heated Back Seat
Standard
Left Window - Sliding
Standard
Right Window - Sliding
Standard
Air Conditioning
Standard
Rear Blind
Optional
Cat Radio/Cd/Mp3/Wma Player
Optional
Sun Visor
Standard
Radio-Ready Kit (Wiring, Speaker, Antenna And Grilles)
Standard
External Mirrors (2) - Knock Back
Standard
Heater
Standard
Lockable Storage Box
Standard
Adjustable Internal Mirror
Standard
