Caterpillar 930G Integrated Tool Carrier
Dimensions
Dimensions
Length W/ Bucket On Ground
24.28ft in
Width Over Tires
8.06ft in
Height To Top Of Cab
10.76ft in
Wheelbase
9.52ft in
Ground Clearance
1.2ft in
Hinge Pin Max Height
13.29ft in
Dump Clearance At Max Lift
9.6ft in
Max Lift Height
12.76ft in
Fork Tine Length
3.94ft in
Hook Height At Max Lift - Standard
22.44ft in
Hook Height At Max Lift - Extended
25.39ft in
Hook Reach At Max Lift - Standard
7.3ft in
Hook Reach At Max Lift - Extended
5.87ft in
Height - Top Of Rops/Fops
10.5ft in
Height - Top Of Hood
85.2in
Height - Top Of Exhaust Stack
10.4ft in
Height - Center Of Axle
2.1ft in
Dump Clearance At Maximum Lift - 45 Degrees
9.1ft in
Bucket Clearance-Maximum Lift/Carry
11.5ft in
Dump Angle At Maximum Lift
45degrees
Length - Rear Axle To Bumper
6.4ft in
Digging Depth
5in
Length With Out Forks On Ground
25.14ft in
Centerline Of Front Axle To Hitch
4.7ft in
Overall Height
16.9ft in
Overall Height - Bucket Raised
16.9ft in
Overall Length
23.6ft in
Rack Back Angle - Carry
51degrees
Rack Back Angle - Ground
50degrees
Rack Back Angle - Maximum Lift
58degrees
Reach At Max Height And Dump
3.55ft in
Reach At Maximum Lift And 45 Degrees Dump
3.6ft in
Wheel Base
9.2ft in
Wheel Base Length
9.2ft in
Carry Height
1.2ft in
Width - Over Tires
8ft in
Bucket Pin Height - Maximum Lift
12.6ft in
Specifications
Engine
Engine Make
2236
Engine Model
366 in
Gross Power
161hp
Net Power
150.2hp
Displacement
366.2cu in
Bore
4in
Stroke
5in
Rated Net Power
149hp
Sae J1349 (2)
159hp
Iso 9249 (1997) (2)
161hp
Eec 80/1269 (2)
161hp
Sae J1349 (1)
149hp
Iso 9249 (1997) (1)
150hp
Eec 80/1269 (1)
150hp
Maximum Net Power - 2000 Rpm
159hp
Operational
Operating Weight
27963.5lb
Fuel Capacity
59.5gal
Cooling System Fluid Capacity
10.6gal
Engine Oil Capacity
4.3gal
Transmission Fluid Capacity
9.2gal
Front Diff Fluid Capacity
6.9gal
Rear Diff Fluid Capacity
6.7gal
Hydraulic System Fluid Capacity
33.1gal
Turning Radius
17.3ft in
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Static Tipping Load - Bucket
20833.7lb
Static Tipping Load - Forks
15943.9lb
Static Tipping Load - Material Handler
8212.3lb
Tire Size
20.5R25
Transmission
Transmission Type
countershaft
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed Forward
23.7mph
Max Speed Reverse
15.6mph
Forward - 1
4.5mph
Reverse - 1
4.5mph
Steering
Steering Angle - Each Direction
40degrees
Minimum Turning Radius - Over Tires
207in
Steering Cylinder, Two, Bore
2.8in
Hydraulic Output At 2300 Engine Rpm And 6900 Kpa (1000 Psi)
17.6 gal/min
Maximum Working Pressure
3500 psi
Steering Articulation
40degrees
Transmission
2
7.6mph
3
15mph
4
23.8mph
Weights
Operating Weight
28725lb
Tires
Tread Width
7.9ft in
Size
17.5-25 12PR L-2
Weights
Optional Counterweight
1036.2lb
Maximum Weight
29044lb
Buckets
Bucket Capacities
2.1 m3 - 5.0 m3 2.6 yd3 - 6.5 yd3
Bucket Width
8.4ft in
Hydraulic System
Pump Type
variable-displacement axial piston
Relief Valve Setting
3756.5psi
Pump Flow Capacity
58.2gal/min
Raise Time
5sec
Dump Time
1.7sec
Lower Time
2.8sec
Bucket
Breakout Force
30349.3lb
Blade
Width
8.4ft in
Bucket
Bucket Capacity - Heaped
2.8yd3
Bucket Capacity - Struck
2.3yd3
Axles
Axle Oscillation
11degrees
Operating Specifications
Static Tipping Load - Full Turn
18029lb
Dump Clearance
9.3ft in
Articulation Angle
40degrees
Reach - Full Lift And 45 Degrees Dump
3.6ft in
Dump Clearance At Full Lift And 45 Degrees Dump Angle
9.7ft in
Service Refill Capacities
Cooling System
10.6gal
Fuel Tank
59.4gal
Crankcase
4.2gal
Hydraulic Tank
18.5gal
Hydraulic System - Including Tank
33gal
Transmission
9.1gal
Front
6.9gal
Rear
6.6gal
Cab
Rops
SAE J1040 MAY94, ISO 3471-1994
Fops
SAE J/ISO 3449 APR98 Level II, ISO 3449 1992 Level II
Loader Hydraulic System
Pump Flow - Implement Pump
58 gal/min
Output At 2,300 Engine Rpm And 6900 Kpa (1000 Psi) With Sae 10w Oil At 65 Degreesc (150 Degreesf)
58 gal/min
Maximum Working Pressure
3755 psi
Raise
5 s
Dump
1.7 s
Lower, Empty, Float Down
2.8 s
Total
9.5 s
Bore (1)
4.5in
Stroke (1)
30.6in
Bore (2)
6in
Stroke (2)
37in
Hydraulic Cycle Time
9.5sec
Relief Pressure - Implement Pump
3755 psi
