Caterpillar 933C Crawler Loader
Units
Dimensions
Dimensions
A
Length With Bucket On Ground
14.28ft in
E
Ground Clearance
1.29ft in
B
Width To Outside Of Tracks
5.92ft in
C
Height To Top Of Cab
8.96ft in
G
Clearance At Full Height And Dump
8.4ft in
H
Reach At Dump Height
2.82ft in
F
Length To Front Of Track
9.7ft in
Undercarriage
I
Track Gauge
57.09in
D
Length Of Track On Ground
6.73ft in
Number Of Shoes Per Side
39
Ground Contact Area
2263.01in2
Ground Pressure
7.84psi
Number Of Track Rollers Per Side
6
Track Shoe Width
14.02in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3046
Net Power
70hp
Power Measured @
2400rpm
Displacement
305.2cu in
Operational
Operating Weight
18706.3lb
Fuel Capacity
41.5gal
Cooling System Fluid Capacity
5.6gal
Engine Oil Capacity
3.5gal
Final Drive Fluid Capacity - Each
3.7gal
Hydraulic System Fluid Capacity
15.1gal
Static Tipping Load
12833.2lb
Breakout Force - Std Bucket
17390lb
Bucket Capacity - Struck
1.4yd3
Bucket Capacity - Heaped
1.1yd3
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Max Speed
5.6mph
Hydraulic
Pump Type
open centered parallel.
Pump Flow Capacity
27.3gal/min
Relief Valve Pressure
2874.7psi
Raise Time
8.8sec
Dump Time
1.7sec
Lower Time
2sec
