Caterpillar 951C Crawler Loader
Units
Dimensions
Dimensions
A
Length With Bucket On Ground
15.67ft in
E
Ground Clearance
1.32ft in
B
Width To Outside Of Tracks
6.5ft in
C
Height To Top Of Cab
9.42ft in
G
Clearance At Full Height And Dump
9.09ft in
H
Reach At Dump Height
3.42ft in
F
Length To Front Of Track
10.83ft in
Undercarriage
I
Track Gauge
60.04in
D
Length Of Track On Ground
7.03ft in
Number Of Shoes Per Side
39
Number Of Track Rollers Per Side
5
Ground Contact Area
2356.01in2
Track Shoe Width
13.98in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3304
Net Power
95hp
Power Measured @
2200rpm
Displacement
427.2cu in
Operational
Operating Weight
28071.5lb
Fuel Capacity
52.1gal
Cooling System Fluid Capacity
6.5gal
Engine Oil Capacity
5gal
Final Drive Fluid Capacity - Each
2.6gal
Hydraulic System Fluid Capacity
19.5gal
Static Tipping Load
18867.2lb
Breakout Force - Std Bucket
15710lb
Bucket Capacity - Struck
1.6yd3
Bucket Capacity - Heaped
1.8yd3
Operating Voltage
24V
Alternator Supplied Amperage
19amps
Max Speed
7.2mph
Hydraulic
Pump Type
Vane-type pump
Pump Flow Capacity
33.3gal/min
Relief Valve Pressure
2500psi
Raise Time
6.6sec
Dump Time
2.4sec
Lower Time
2.3sec
