Caterpillar AD45B Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
36.73ft in
B
Overall Width
9.85ft in
C
Overall Height
9.97ft in
D
Wheelbase
18.28ft in
E
Ground Clearance
1.45ft in
F
Dump Height
20.86ft in
G
Dump Ground Clearance
2.19ft in
Dump
Lower Time
21sec
Raise Time
16sec
Capacity - Heaped
27.9yd3
Specifications
Engine
Engine Make
2236
Engine Model
C18 ACERT
Gross Power
587hp
Net Power
556hp
Power Measured @
2000rpm
Displacement
1104.6cu in
Operational
Fuel Capacity
201.8gal
Hydraulic System Fluid Capacity
70.3gal
Cooling System Fluid Capacity
22.5gal
Engine Oil Capacity
16.9gal
Transmission Fluid Capacity
15.9gal
Tire Size
29.5 x R29
Transmission
Number Of Forward Gears
7
Number Of Reverse Gears
2
Max Speed
32.3mph
Weights
Front Axle - Empty
60847lb
Rear Axle - Empty
27337lb
Front Axle - Loaded
85451%
Rear Axle - Loaded
101942lb
Total Empty
88184lb
Total Loaded
187393lb
