Caterpillar CB14 XW - 1000 mm Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
6.67ft in
B
Overall Width
3.5ft in
Height - Steering Wheel
64in
Maximum Machine Height
94in
Wheel Base
4.25ft in
Drum Diameter
22.5in
Operating Specifications
E
Ground Clearance
0.84ft in
Standard Compaction Width
39in
Static Linear Load
52lb
Travel Speed - Maximum
5mph
Turning Radius - Inside Drum Edge
8.5in
Curb Clearance
14.5in
Specifications
Engine
Gross Power
22hp
Engine Model
C1.1
Operational
Operating Weight
4057lb
Drum
Drum Width
31in
Weights
Maximum Weight At Front Drum
1851lb
Maximum Weight At Rear Drum
2204lb
Service Refill Capacities
Fuel Tank Capacity
7.9gal
Water Spray Tank Capacity
39.6gal
Vibratory System
Nominal Amplitude - High
0.1in
Centrifugal Force Per Drum - Maximum
2565lb
Frequency
3200 V/m
