Caterpillar CB14B - 1000 mm (39") Drums Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
77ft in
B
Overall Width
43ft in
Drum Diameter
22in
Maximum Machine Height
100in
Operating Specifications
E
Ground Clearance
9ft in
Travel Speed - Maximum
6mph
Standard Compaction Width
39in
Static Linear Load
42.9lb
Curb Clearance
16in
Specifications
Engine
Gross Power
22.5hp
Engine Model
Kohler KDW1003
Operational
Operating Weight
3351lb
Drum
Drum Width
39in
Weights
Maximum Weight At Front Drum
1676lb
Maximum Weight At Rear Drum
1675lb
Service Refill Capacities
Fuel Tank Capacity
6.1gal
Water Spray Tank Capacity
26.4gal
Vibratory System
Nominal Amplitude - High
0.1in
Centrifugal Force Per Drum - Maximum
3400lb
Frequency
3900 V/m
