Caterpillar CC34B Compactor
Units
Dimensions
Dimensions
E
Ground Clearance
11ft in
D
Wheelbase
81ft in
Maximum Machine Height
109in
Overall Length
9.42ft in
Overall Width
4.59ft in
Drum Diameter
32in
Wheel Base
6.75ft in
Operating Specifications
E
Ground Clearance
0.92ft in
Standard Compaction Width
51in
Static Linear Load
73lb
Travel Speed - Maximum
7.5mph
Turning Radius - Inside Drum Edge
115.2in
Curb Clearance
20in
Specifications
Engine
Engine Make
2236
Engine Model
C2.2
Gross Power
48.8hp
Engine Model
C2.2
Operational
Operating Weight
7446lb
Fuel Capacity
24gal
Drum
Drum Width
51in
Transmission
Max Speed
7.5mph
Weights
Operating Weight
7446lb
Maximum Weight At Front Drum
3974lb
Maximum Weight At Rear Drum
3147lb
Maximum Weight At Rear Wheels
3472lb
Service Refill Capacities
Fuel Tank Capacity
24gal
Water Spray Tank Capacity
64gal
Vibratory System
Nominal Amplitude - High
0.1in
Centrifugal Force Per Drum - Maximum
7104lb
Frequency
55/48 Hz (3,300/2880 vpm)
Centrifugal Force Per Drum - Minimum
5418lb
