Caterpillar D5C Series III Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
13.36ft in
C
Height To Top Of Cab
8.99ft in
E
Ground Clearance
1.26ft in
F
Length W/O Blade
9.85ft in
Bulldozer Blade Width - Straight
9ft in
Overall Height
9ft in
Undercarriage
G
Track Gauge
5.09ft in
Number Of Track Rollers Per Side
6
Specifications
Engine
Engine Model
3046T
Displacement
305cu in
Engine Model
Cat 3046
Power - Gross
100hp
Power - Net
90hp
Operational
Operating Weight
18580lb
Fuel Capacity
41.5gal
Transmission
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6mph
Weights
Operating Weight - Xl
18580lb
Operating Specifications
Dig Depth - Vpat Blade
19in
Lift Height - Vpat Blade
32in
Maximum Tilt - Vpat Blade
16in
Maximum Angle - Vpat Blade
25degrees
