Caterpillar D8L LGP Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
20.44ft in
B
Width Over Tracks
10.44ft in
C
Height To Top Of Cab
12.7ft in
D
Length Of Track On Ground
10.55ft in
E
Ground Clearance
1.51ft in
F
Length W/O Blade
16.25ft in
Undercarriage
G
Track Gauge
8.34ft in
H
Standard Shoe Size
35.99in
Number Of Track Rollers Per Side
8
Ground Contact Area
9098.52in2
Specifications
Engine
Engine Make
2236
Engine Model
3408
Gross Power
335hp
Displacement
1098.5cu in
Operational
Operating Weight
87045.2lb
Fuel Capacity
199gal
Transmission
Transmission Type
powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
7.4mph
Max Speed - Reverse
9.2mph
Standard Blade
Width
13.7ft in
Height
71in
Capacity
14.4yd3
Cutting Depth
25.9in
