Caterpillar E110B Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
I
Max Cutting Height
25.12ft in
J
Max Loading Height
17.36ft in
K
Max Reach Along Ground
23.94ft in
L
Max Vertical Wall Digging Depth
13.87ft in
M
Max Digging Depth
15.59ft in
Boom/Stick Option (Hex) 1
Stick 6'5" (1950mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
25.58ft in
J
Max Loading Height
17.85ft in
K
Max Reach Along Ground
24.84ft in
L
Max Vertical Wall Digging Depth
14.6ft in
M
Max Digging Depth
16.57ft in
Boom/Stick Option (Hex) 2
Stick 7'5" (2250mm)
Boom/Stick Option (Hex) 3
I
Max Cutting Height
26.65ft in
J
Max Loading Height
18.92ft in
K
Max Reach Along Ground
26.58ft in
L
Max Vertical Wall Digging Depth
16.29ft in
M
Max Digging Depth
18.38ft in
Boom/Stick Option (Hex) 3
Stick 9'2" (2800mm)
Dimensions
E
Ground Clearance
1.51ft in
G
Height To Top Of Cab
8.86ft in
B
Width To Outside Of Tracks
8.17ft in
D
Length Of Track On Ground
8.57ft in
H
Tail Swing Radius
6.86ft in
Removal Counterweight Clearance
3.02ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
19.69in
Max Travel Speed
3.11mph
Ground Pressure
5.69psi
Drawbar Pull
19333.57lb
Specifications
Engine
Engine Make
2236
Engine Model
3114
Gross Power
79.2hp
Displacement
268.6cu in
Operational
Operating Weight
25573.7lb
Fuel Capacity
66.1gal
Hydraulic System Fluid Capacity
42.3gal
Hydraulic System Relief Valve Pressure
4270psi
Hydraulic Pump Flow Capacity
56.6gal/min
