Caterpillar E200B Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.85ft in
C
Shipping Height Of Unit
9.9ft in
I
Max Cutting Height
29.14ft in
J
Max Loading Height
19.85ft in
K
Max Reach Along Ground
29.04ft in
L
Max Vertical Wall Digging Depth
15.82ft in
M
Max Digging Depth
18.64ft in
Boom/Stick Option (Hex) 1
Boom 5750mm w/ stick 6\'3\" (1900mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.21ft in
I
Max Cutting Height
30.06ft in
C
Shipping Height Of Unit
9.85ft in
J
Max Loading Height
21.33ft in
K
Max Reach Along Ground
30.76ft in
L
Max Vertical Wall Digging Depth
17.39ft in
M
Max Digging Depth
20.36ft in
Boom/Stick Option (Hex) 2
Boom 5750mm w/ stick 8\'2\" (2500mm)
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
31.11ft in
I
Max Cutting Height
30.99ft in
J
Max Loading Height
21.95ft in
C
Shipping Height Of Unit
9.75ft in
K
Max Reach Along Ground
32.34ft in
L
Max Vertical Wall Digging Depth
19.95ft in
M
Max Digging Depth
22.02ft in
Boom/Stick Option (Hex) 3
Boom 5750mm w/ stick 9\\\'9\\\" (2975mm)
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
31.12ft in
C
Shipping Height Of Unit
11.06ft in
I
Max Cutting Height
31.68ft in
J
Max Loading Height
22.74ft in
K
Max Reach Along Ground
34.86ft in
M
Max Digging Depth
24.92ft in
Max Vertical Wall Dig Depth
22.09ft in
Boom/Stick Option (Hex) 4
Boom 5750mm w/ stick 12\'8\" (3860mm)
Dimensions
E
Ground Clearance
1.53ft in
G
Height To Top Of Cab
9.29ft in
B
Width To Outside Of Tracks
9.19ft in
H
Tail Swing Radius
9.03ft in
Removal Counterweight Clearance
3.38ft in
Undercarriage
F
Track Gauge
7.22ft in
N
Shoe Size
23.63in
Drawbar Pull
38100lb
Max Travel Speed
3.11mph
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
45
Ground Pressure
6.3psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3116
Net Power
118hp
Power Measured @
1800rpm
Displacement
402.8cu in
Aspiration
turbocharged
Operational
Operating Weight
41447lb
Fuel Capacity
74gal
Cooling System Fluid Capacity
6.1gal
Hydraulic System Fluid Capacity
66.1gal
Engine Oil Capacity
4gal
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Hydraulic System Relief Valve Pressure
4550psi
Hydraulic Pump Flow Capacity
94.1gal/min
Buckets
Reference Bucket Capacity
0.8yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1.4yd3
