Caterpillar EL240B Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.93ft in
C
Shipping Height Of Unit
9.91ft in
I
Max Cutting Height
30.16ft in
J
Max Loading Height
20.64ft in
K
Max Reach Along Ground
30.84ft in
L
Max Vertical Wall Digging Depth
16.51ft in
M
Max Digging Depth
20.05ft in
Boom/Stick Option (Hex) 1
Stick 7'3" (2200mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.93ft in
I
Max Cutting Height
31.5ft in
C
Shipping Height Of Unit
9.91ft in
J
Max Loading Height
21.79ft in
K
Max Reach Along Ground
32.81ft in
L
Max Vertical Wall Digging Depth
19.39ft in
M
Max Digging Depth
22.02ft in
Boom/Stick Option (Hex) 2
Stick 9'2" (2800mm)
Boom/Stick Option (Hex) 3
I
Max Cutting Height
31.93ft in
J
Max Loading Height
22.25ft in
K
Max Reach Along Ground
34.78ft in
L
Max Vertical Wall Digging Depth
21.49ft in
M
Max Digging Depth
24.32ft in
Boom/Stick Option (Hex) 3
Stick 11'6" (3500mm)
Dimensions
E
Ground Clearance
1.55ft in
G
Height To Top Of Cab
9.78ft in
B
Width To Outside Of Tracks
11.09ft in
D
Length Of Track On Ground
12.21ft in
H
Tail Swing Radius
9.52ft in
Removal Counterweight Clearance
3.61ft in
Undercarriage
F
Track Gauge
8.47ft in
N
Shoe Size
31.5in
Max Travel Speed
2.12mph
Ground Pressure
5.26psi
Number Of Shoes Per Side
50
Drawbar Pull
41140.04lb
Number Of Track Rollers Per Side
8
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3116
Net Power
148hp
Power Measured @
2200rpm
Displacement
402.8cu in
Aspiration
turbocharged
Operational
Operating Weight
52029.1lb
Fuel Capacity
74gal
Cooling System Fluid Capacity
7gal
Hydraulic System Fluid Capacity
79.3gal
Engine Oil Capacity
4gal
Operating Voltage
24V
Swing Drive Fluid Capacity
2.6gal
Alternator Supplied Amperage
55amps
Hydraulic System Relief Valve Pressure
3983psi
Hydraulic Pump Flow Capacity
121.6gal/min
Swing Mechanism
Swing Speed
10.2rpm
Buckets
Reference Bucket Capacity
1.3yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
2.4yd3
