Caterpillar M318C MH Material Handler
Units
Dimensions
Boom/Stick Option (Mat) 1
I
Max Height
39.05ft in
J
Max Reach Along Ground
34.45ft in
K
Max Depth
6.89ft in
Boom/Stick Option (Mat) 1
Boom 6200mm / Stick 4900mm
Boom/Stick Option (Mat) 2
I
Max Height
36.91ft in
J
Max Reach Along Ground
32.16ft in
K
Max Depth
4.93ft in
Boom/Stick Option (Mat) 2
Boom 6200mm / Stick 4200mm
Dimensions
E
Ground Clearance
0.96ft in
A
Shipping Length
29.73ft in
B
Undercarriage Width
9.81ft in
C
Shipping Height
11.42ft in
G
Height To Top Of Cab - Fixed Riser
10.6ft in
H
Height To Top Of Cab - Hydraulic Riser Raised
18.48ft in
L
Upperstructure Clearance
4.29ft in
Tail Swing Radius
8.21ft in
Wheel Undercarriage
D
Wheelbase
9.03ft in
F
Width W/ Stabilizers On Ground
14.31ft in
Tire Size
10.00-20
Steering Angle
35degrees
Axel Oscillation
18degrees
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3056E DIT ATAAC
Gross Power
159hp
Net Power
151hp
Power Measured @
2000rpm
Displacement
366.2cu in
Aspiration
Turbocharged
Operational
Operating Weight W/O Attachment
47311.3lb
Fuel Capacity
101.8gal
Cooling System Fluid Capacity
10.4gal
Engine Oil Capacity
4.3gal
Hydraulic System Fluid Capacity
67.4gal
Alternator Supplied Amperage
75amps
Max Drawbar Pull
205.7lb
Swing Mechanism
Swing Speed
10.5rpm
Swing Torque
29576.3lb ft
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed
15.6mph
Hydraulic
Pump Capacity
105.7gal/min
Relief Pressure
5076.4psi
