Caterpillar P5000 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
8.37ft in
B
Overall Width
3.78ft in
C
Overall Height - Mast Lowered
7.03ft in
D
Wheelbase
5.25ft in
E
Ground Clearance
4.61in
F
Height To Top Of Overhead Guard
6.91ft in
G
Max Fork Height
10.96ft in
Turning Radius
7.32ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
10degrees
Max Fork Spread
39.38in
Lower Speed
98ft/min
Load Center
19.69in
Load Capacity
5511.56lb
Lift Speed
130ft/min
Specifications
Engine
Engine Model
K25
Power
63hp
Torque
139lb ft
Power Measured @
2700rpm
Displacement
152cu in
Torque Measured @
1600rpm
Fuel Type
gas
Operational
Operating Weight
7900lb
Tire Type
pneumatic
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
11.5mph
