Challenger MT535B 2WD 2WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
15.19in
D
Wheelbase
9.28ft in
B
Overall Width
6.76ft in
E
Ground Clearance
15.44in
Height With Rops
9.4ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
C6.6 ACERT
Pto Power
110hp
Power Measured @
2200rpm
Displacement
402.8cu in
Aspiration
Turbocharged and Aftercooled
Operational
Operating Weight
11052lb
Fuel Capacity
71.4gal
Cooling System Fluid Capacity
6.8gal
Hydraulic System Fluid Capacity
18.5gal
3 Point Hitch Lift Capacity @ 24 Inches
10915lb
Operating Voltage
24V
Alternator Supplied Amperage
120amps
Transmission
Transmission Type
Auto Power
Max Speed
25mph
Hydraulic System
Relief Valve Setting
2900psi
Pump Flow Capacity
29.1gal/min
Number Of Remote Control Valves
2
