Claas Celtis 446 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
15.18in
B
Width Outside Frame
8.24ft in
C
Height To Top Of Cab
8.71ft in
D
Wheelbase
8.17in
Tire Size
Front 13.6R28, Rear 16.9 R 34
Specifications
Engine
Number Of Cylinders
4
Engine Make
2467
Engine Model
ECE-R24
Gross Power
90.6hp
Net Power
88.6hp
Power Measured @
2200rpm
Displacement
276.2cu in
Operational
Fuel Capacity
38.4gal
Operating Weight
9722.4lb
Turning Radius
14.2ft in
Operating Voltage
12V
Alternator Supplied Amperage
75amps
Transmission
Transmission Type
CLAAS
Number Of Forward Gears
20
Number Of Reverse Gears
20
Max Speed
24.9mph
Hydraulic System
Pump Flow Capacity
15.9gal/min
Relief Valve Pressure
2610.7psi
