Clark Michigan TMX15 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.35ft in
B
Overall Width
3.36ft in
C
Overall Height - Mast Lowered
6.92ft in
D
Wheelbase
4.4ft in
E
Ground Clearance
3.25in
F
Height To Top Of Overhead Guard
6.92ft in
G
Max Fork Height
13.03ft in
Right Angle Stack
6.19ft in
Turning Radius
4.99ft in
Mast
H
Mast Tip Forward
3degrees
I
Mast Tip Rear
5degrees
Number Of Mast Sections
4
Lower Speed
77ft/min
Max Fork Spread
35.99in
Load Center
19.69in
Load Capacity
3306.94lb
Lift Speed
69ft/min
Specifications
Engine
Fuel Type
Electric Motor 36V
Operational
Operating Weight
7921.3lb
Tire Type
Cushion
Number Of Front Wheels
2
Number Of Rear Wheels
1
Max Speed
9.4mph
